DU1A
37
Pattern side
BOOT SW
CONTROLLER (CTRL) Circuit Board
CONTROLLER (CTRL): V804180
HP: V900040
to MN-CN104
to MN-CN106
to MN-CN5
REVERBVOLUME HEADPHONES
to MN-CN105
AUX
OUT
IN
HP (1/2) Circuit Board
HP (2/2) Circuit Board
Component side
Component side
