CONTROLS
4-5
J0C
TOW SWITCH
Before operating the car, make
sure the tow switch is in the “RUN”
position.
å Tow switch
Ensure that the “Drive Select
Switch” is in the “FWD” position
and then move the “TOW Switch”
to “TOW” before towing.
After moving switch from “RUN”
to “TOW,” wait 15 seconds mini-
mum before switching again.
Failure to do so may lead to drive
system damage while towing.
NOTICE
Y-1995
TOW
RUN
A
