9-3
J0C
General Specifications
DC Output – see Operating Instructions
AC Input
Mechanical
Voltage - nom (V) 48
Voltage - max (V) 67.2
Current - max (A) 18
Battery Type Specific to selected algorithm
Reverse Polarity Electronic protection – auto-reset
Short Circuit Electronic current limit
Voltage - max (Vrms) 85-265
Frequency (Hz) 45-65
Current - max (Arms)
12A @ 104VAC / 11.5A @ 110VAC /
6.1A @ 200VAC / 5.6A @ 220VAC /
5.4A @ 230VAC / 5.1A @ 240VAC
Current - nom (Arms)
10A @ 120VAC / 6A @ 200VAC /
5A @ 230VAC
AC Power Factor >0.98 at nominal input current
Dimensions
28.0 x 24.5 x 11.0 cm
(11 x 9.7 x 4.3")
Weight <5 kg (12 lbs)
Environmental Enclosure: IP46
Operating Temperature
-30°C to +50°C ( -22°F to 122°F),
derated above 30°C, below 0°C
Storage Temperature -40°C to +70°C (-40°F to 158°F)
AC Input Connector
IEC320/C14
(require ≥ 1.8 m localized cord)
Safety Timeout 20.5 hours (24.5 hours when boosting)
SPECIFICATIONS
BATTERY CHARGER
