No. Port No.
Function name
I/O Detail of function
44 P52 /ICCS O CS493x Reset
45 P51 /CSPLD O Digital External Control IC CE
For Flash Writing (HI)
CS-DSP INT/ABOOT
Headphone Mute Output
Clock Line for BD38xx System Control
Data Line for BD38xx System Control
Microprocessor Power Supply, +5V
Microprocessor Ground
Y/C Separation Select
PLL IC Enable/Destination Discriminate 1
PLL IC Clock/Destination Discriminate 0
Tuned
Tuner/ST
Tuner Mute
Protection Excess Current Detect
Power Limiter A
Power Limiter B
Connection Discriminate
Protection DC Detect
Temperature Detect
Open
Key AD Input 0
Key AD Input 1
AD Ground
Protection Power Supply Voltage Detect
AD Reference
AD Power Supply
IC601: M3062VMGP (FUNCTION P.C.B.)
16bit µ-COM (Main CPU)
