Data List
MIDI Data Format
1. General
1.1 Scope
The specifications described herein apply to transmission and reception of MIDI
databytheDTX-MULTI12.
1.2 Compliance
ThespecicationsdescribedhereincomplywiththeMIDI1.0standard.
1.3 Legend
Thefollowingsymbolshaveaspecialmeaningherein.
$:Placedinfrontofhexadecimalnumbers.•
$nn:Indicatesmultipledigits.•
2. Channel Messages
Channel messages on MIDI channel 10 are not received when the Rcv10ch
parameterontheUTILITYsettingarea’sChannel-10Receivepage(UTIL6-1)isset
to“off”.
2.1 Key On & Key Off
KeyOnandKeyOffmessagesaretransmittedandreceived.
Rangeofnotesreceived:0(C-2)to127(G8)
Velocityrange:1to127(i.e.,NoteOnonly)
2.2 Control Change
The internal sequencer can record and play back all varieties of Control Change
message; accordingly, the DTX-MULTI12 can both transmit and receive all such
messages.Detailspertainingtotheinternaltonegeneratoranddrumtrigger
functionaredescribedbelow.
2.2.1 Bank Select MSB (0), LSB (32)
BankSelectMSBandLSBmessagesaretransmittedandreceived.
MSB=0,LSB=anyvalue:GMinstrumentvoices
MSB=63,LSB=anyvalue:Instrumentvoices
MSB=127,LSB=anyvalue:GMdrumvoices(seeNote1)
MSB=125,LSB=0:Drumvoices,Presetkits(seeNote2)
MSB=125,LSB=1:Drumvoices,Userkits1to100(seeNote3)
MSB=125,LSB=2:Drumvoices,Userkits101to200(seeNote4)
* Note 1: General MIDI drum voices
Only program number 1 is received, and the corresponding GM preset kit is
selected.
* Note 2: Drum voices, Preset kits
The Preset kit having the same number as the received program number is
selected.
* Note 3: Drum voices, User-1 kits
The User kit having the same number as the received program number is
selected.
* Note 4: Drum voices, User-2 kits
The User kit having a number 100 greater than the received program number is
selected.
In all of these cases, a drum voice can be selected for MIDI channels other than
channel10;however,thedrummapusedisidenticaltothatforchannel10.
2.2.2 Modulation (1)
Modulationmessagesarereceivedbutnottransmitted.
2.2.3 Foot Controller (4)
FootControllermessagesaretransmittedandreceived.
2.2.4 Portamento Time (5)
PortamentoTimemessagesarereceivedbutnottransmitted.
2.2.5 Data Entry (6)
DataEntrymessagesarereceivedbutnottransmitted.Thesemessagesareused
tospecifyRPNdata.
2.2.6 Main Volume (7)
MainVolumemessagesaretransmittedandreceived.
2.2.7 Pan (10)
Panmessagesaretransmittedandreceived.Avalueof0correspondstothefar
leftofthestereoimage;avalueof127,tothefarright.
2.2.8 Expression (11)
Expressionmessagesarereceivedbutnottransmitted.
2.2.9 EG Sustain Level (31)
EGSustainLevelmessagesarereceivedbutnottransmitted.
2.2.10 Hold 1 (64)
Hold1messagesarereceivedbutnottransmitted.
2.2.11 Portamento Switch (65)
PortamentoSwitchmessagesarereceivedbutnottransmitted.
2.2.12 Sostenuto (66)
Sostenutomessagesarereceivedbutnottransmitted.
2.2.13 Harmonic Content (71)
HarmonicContentmessagesarereceivedbutnottransmitted.
2.2.14 EG Release Time (72)
EGReleaseTimemessagesarereceivedbutnottransmitted.
2.2.15 EG Attack Time (73)
EGAttackTimemessagesarereceivedbutnottransmitted.
2.2.16 Brightness (74)
Brightnessmessagesarereceivedbutnottransmitted.
2.2.17 EG Decay Time (75)
EGDecayTimemessagesarereceivedbutnottransmitted.
2.2.18 Effect 1 Depth (91)
Effect1Depthmessagesaretransmittedandreceived.Themessagevalue
correspondstotheReverbSendlevel.
2.2.19 Effect 3 Depth (93)
Effect3Depthmessagesaretransmittedandreceived.Themessagevalue
correspondstotheChorusSendlevel.
2.2.20 Effect 4 Depth (94)
Effect4Depthmessagesaretransmittedandreceived.Themessagevalue
correspondstoVariationSendlevel.
2.2.21 Data Increment (96), Decrement (97)
DataIncrementandDecrementmessagesarereceivedbutnottransmitted.
2.2.22 RPN
$00/$00Pitchbendsensitivity:Receivedbutnottransmitted.
$00/$01Finetuning:Receivedbutnottransmitted.
$00/$02Coarsetuning:Receivedbutnottransmitted.
$7f/$7fNULL:Receivedbutnottransmitted.
2.2.23 HH Controllers (1 to 95)
If, within the KIT setting area, the HH Func parameter on the Hi-hat Function page
(KIT7-3)issetto“MIDI”andtheHHMIDITypeparameterfromtheHi-hatMIDI
Typepage(KIT7-5)issettoanyvaluebetween“CC01”and“CC95”,aControl
Change message with the corresponding control change number will be sent
wheneverthehi-hatcontrollerispressed.
2.2.24 Kit Transmit MIDI (1 to 95)
If the CCNo parameter on the MIDI setting area’s CC Number & Value page
(MIDI3-8)istoavaluebetween“1”and“95”foraspecickit,aControlChange
message with the corresponding control change number will be sent whenever
thatkitisselected.
2.2.25 MIDI Message Type (1 to 95)
If the MessageType parameter on the MIDI setting area’s Select Message Type
page(MIDI1)issetto“CC”foraspecicpad,aControlChangemessagewiththe
control change number specified by the CCNo parameter on the Control Change
Number&Valuepage(MIDI1-1)will,uponstrikingofthatpad,besentviathe
MIDIOUTconnectorbutnottotheinternaltonegenerator.
2.2.26 Pad Function (1 to 95)
IftheFuncparameterfromtheUTILITYsettingarea’sPadFunctionpage(UTIL4-
1)issettoanyvaluebetween“CC01”and“CC95”foraspecicpad,aControl
Change message with the corresponding control change number will be sent
uponstrikingofthatpad.
