DTX500 Owner’s Manual
Appendix
Specifications
* Specifications and descriptions in this owner’s manual are for information purposes only. Yamaha Corp. reserves the right to change or mod-
ify products or specifications at any time without prior notice. Since specifications, equipment or options may not be the same in every locale,
please check with your Yamaha dealer.
MIDI Data Format
1. Channel Messages
The channel messages described below are sent from
the drum triggers only. Other messages are sent from
both the drum triggers and the sequencer.
1.1 Key On, Key Off
Note range: 0 (C-2)–127 (G8)
Velocity range: 0–127
1.2 Control Change
1.2.1 Bank select MSB, LSB–0, 32
data = 0–127
1.2.2 Foot controller–4 (Ch. 10 only)
1.2.3 Main volume–7
1.2.4 Pan–10 (left 0, right 127)
1.3 Program Change
2. System Exclusive Messages
2.1 Parameter Change
2.1.1 GM system ON
$F0 $7E $7F $09 $01 $F7 (hexadecimal)
Sets all messages (except MIDI master tun-
ing) to their initial values.
3. System Realtime Message
3.1 Timing clock
Sends data.
3.2 Start, Stop
Sends data.
3.3 Active sensing
Sends the messages within an interval of approxi-
mately 300 msec.
Tone Genera-
tor block
Tone Generator AWM2
Maximum Polyphony 32
Voices 427 Drum, Percussion Voices, 22 Keyboard Voices
Drum Kits Preset: 50, User: 20
Effects Reverb x 19 types, Master EQ
Trigger
Tr igger Setups Preset: 7, User: 4
Pad Controller Snares adjustment, Tuning, Tempo
Pad Functions Drum Kit INC/DEC, Click Set INC/DEC, Tempo INC/DEC, Click ON/OFF
Pad Songs Start/Stop, Chase, Cut Off, 3 songs (max.) can be played simultaneously.
Sequencer
Note Capacity Approx. 16,000 notes
Note Resolution 96 parts per quarter note
Recording Type Real Time Replace
Tra ck 1
Songs 3 Demo Songs, 41 Practice Songs, 19 Pad Songs, 20 User Songs
Metronome
Tempo 30–300 beats/minute, Tap Tempo function
Beat 1–9
Timing Accent, Quarter note, Eighth note, Sixteenth note, Triplet
Click Sound Sets Preset: 6, User: 1
Click Sets 30
Click Timer 0–600 seconds (in 30-second steps)
Training Functions Measure Break, Groove Check, Rhythm Gate
Others
Controls
Buttons: DRUMKIT, CLICK, SONG
>
/
■
, SHIFT,
<
,
>
, ON/OFF, SAVE/ENTER
Controllers: Volume, Jog Dial
Displays 16 characters x 2 lines backlit LCD, 7-segment LED (3-digit), Tempo LED x 2
Connectors Trigger inputs 1, 5, 6, 7 (stereo phone jack L: trigger input, R: rim switch)
Tr igger inputs 2, 3, 4, 8 (stereo phone jack L: trigger input, R: trigger input)
HI HAT CONTROL (stereo phone jack)
OUTPUT L/MONO, R (mono phone jack)
PHONES (stereo phone jack), AUX IN (stereo mini jack)
MIDI OUT, DC IN
Power Consumption 8.0W (DTX500), 13.0W (DTX500 and AC power adapter)
Dimensions (W x D x H) 252 x 147 x 52 mm (9-15/16" x 5-13/16" x 2-1/16")
Weight 898 g (2 lbs.)
