Yamaha E810 - Specifications

67 En
English
ADDITIONAL
INFORMATION
■ RX-E810
AMPLIFIER SECTION
• Minimum RMS output power per channel
(6 Ω , 1 kHz, 0.1% THD) ......................................... 55 W + 55 W
• Maximum RMS output power per channel
(6 Ω , 1 kHz, 1% THD) ............................................ 65 W + 65 W
• Input sensitivity/Impedance
DVD/MD/TAPE/AUX etc. ..................................... 150 mV/47 kΩ
• Frequency Response (20 Hz to 20 kHz)
DVD etc. ........................................................................ 0 ± 0.5 dB
• Total Harmonic Distortion (20 Hz to 20 kHz)
DVD etc. 30 W, 6 Ω.................................................. 0.04% or less
• Signal to Noise ratio (IHF-A network)
DVD etc. (150 mV, Input shorted)........................... 93 dB or more
• Output level/Impedance
PHONES....................................................................0.23 V/120 Ω
TUNER SECTION
FM Section
• Tuning Range
U.S.A., Canada, Asia, and Taiwan models
......................................................................... 87.50-107.90 MHz
Other models.................................................... 87.50-108.00 MHz
AM Section
• Tuning Range
U.S.A., Canada, Asia, and Taiwan models...............530-1710 kHz
Other models.............................................................531-1611 kHz
• Sensitivity
FM (S/N 68 dB).................................................................. 6.0 µV
AM................................................................................. 600 µV/m
GENERAL
• Power Supply
U.S.A. and Canada models.................................. AC 120 V, 60 Hz
Australia model.................................................... AC 240 V, 50 Hz
U.K. and Europe models...................................... AC 230 V, 50 Hz
Korea model......................................................... AC 220 V, 60 Hz
China model......................................................... AC 220 V, 50 Hz
Asia model...............................................AC 220-240 V, 50/60 Hz
Taiwan model...........................................AC 110-120 V, 50/60 Hz
• Power consumption
U.S.A., Canada, and Taiwan models ....................................115 W
Other models.........................................................................130 W
• Standby Power consumption ....................................................0.1 W
• AC Outlets
U.K. and Australia models............................ 1 (Total 100 W max.)
Korea model............................................................................None
Other models................................................. 2 (Total 100 W max.)
• Dimensions (W x H x D).................................. 215 x 108 x 363 mm
• Weight.......................................................................................5.7 kg
■ DVD-E810
PLAYBACK SYSTEM
• DVD video, video CD and SVCD, CD, picture CD, CD-R/RW,
DVD+R/RW, DVD-R/RW
VIDEO PERFORMANCE
• Video (CVBS) Output.............................................. 1 Vpp into 75 Ω
• S-Video output.....................................................Y: 1 Vpp into 75 Ω
C: 305 mVpp into 75 Ω
• RGB (Scart) output........................................... 700 mVpp into 75 Ω
• Component video output......................................Y: 1 Vpp into 75 Ω
PBCB PRCR: 700 mVpp into 75 Ω
AUDIO FORMAT
• Dolby Digital/DTS/MPEG................................. Compressed Digital
PCM ......................................................................... 16, 20, 24 bits
fs, 44.1, 48, 96 kHz
MP3 (ISO 9660)..........................................96, 128, 256, 320 kbps
fs, 32, 44.1, 48 kHz
WMA.................................................................64 kbps - 192 kbps
fs, 44.1, 48 kHz
• Analog Sound............................................................................stereo
LASER
• Type..................................................... Semiconductor laser GaAlAs
• Wave length................................................................650 nm (DVD)
780 nm (VCD/CD)
• Output power................................................................ 7 mW (DVD)
10 mW (VCD/CD)
• Beam divergence .................................................................60 degree
AUDIO PERFORMANCE
• DA Converter ............................................................. 24 bit/192 kHz
• Signal-Noise (1 kHz)...............................................................105 dB
• Dynamic range (1 kHz).............................................................97 dB
• DVD fs 96 kHz 2 Hz - 44 kHz
fs 48 kHz 2 Hz - 22 kHz
• SVCD fs 48 kHz 2 Hz - 22 kHz
fs 44.1 kHz 2 Hz - 20 kHz
• CD/VCD fs 44.1 kHz 2 Hz - 20 kHz
• Distortion and Noise (1 kHz) ..............................................0.0035 %
TV STANDARD (PAL/50 Hz) (NTSC/60 Hz)
• Number of lines 625 525
• Playback Multistandard (PAL/NTSC)
CONNECTIONS
• SCART........................................................................Euroconnector
• Y output........................................................................ Cinch (green)
•PB/CB output.................................................................... Cinch (blue)
•PR/CR output......................................................................Cinch (red)
• S-Video output ........................................................Mini DIN, 4 pins
• Video output..............................................................................Cinch
• Audio output (L+R) ..................................................................Cinch
• Digital output
......................1 coaxicial, 1 optical (IEC60958 for CDDA/LPCM)
(IEC61937 for MPEG2, Dolby Digital)
GENERAL
• Power supply
U.S.A. and Canada models ..................................AC 120 V, 60 Hz
Australia model ....................................................AC 240 V, 50 Hz
U.K. and Europe models ......................................AC 230 V, 50 Hz
Korea model ............................................ AC 110-240 V, 50/60 Hz
China model .........................................................AC 220 V, 50 Hz
• Standby Power consumption................................................. < 1.0 W
• Power consumption..................................................... Approx. 12 W
• Dimensions (W x H x D) ..................................215 x 108 x 330 mm
• Weight ...................................................................................... 2.3 kg
*Specifications are subject to change without notice.
Specifications
