5) With the outboard motor in a vertical
position, and using a flexible or pres-
surized filling device, inject the gear
oil into the oil drain plug hole.
6) When the oil begins to flow out of the
oil level plug hole, insert and tighten
the oil level plug.
7) Insert and tighten the oil drain plug.
Gear oil grade/capacity:
Refer to “SPECIFICATIONS,” page 4-1.
601015
4-26
EMU00831*
INSPECTING AND REPLACING
ANODE(S)
Yamaha outboard motor is protected
from corrosion by a sacrificial anode(s).
Check the anode(s) periodically. Remove
the scales from surfaces of the anode(s).
For the inspection and replacement of the
anode(s), consult a Yamaha dealer.
cC
Do not paint the anode(s), for this would
render it ineffective
NOTE:
Remove the cover with anode after
removing the bolts 1 when checking the
anode condition.
603024
F1027
F1028
q
