5) With the outboard motor in a vertical
position, and using a flexible or pres-
surized filling device, inject the gear
oil into the oil drain plug hole.
6) When the oil begins to flow out of the
oil level plug hole, insert and tighten
the oil level plug.
7) Insert and tighten the oil drain plug.
Gear oil grade/capacity:
Refer to "SPECIFICATIONS," page 4-1.
