E
4-20
EMK78011
CHECKING WIRING AND
CONNECTORS
1) Check that each grounding wire is
properly secured.
2) Check that each connector is engaged
securely.
EMK78110
EXHAUST LEAKAGE
Start the engine and check that no
exhaust leaks from the joints between the
exhaust cover, cylinder head and crank
case.
EMK78210
WATER LEAKAGE
Start the engine and check that no water
leaks from the joints between the exhaust
cover, cylinder head and crank case.
001552
w
q
e
EMU01463
REPLACING FUSE
If the fuse has blown on an Electric start
model, open the fuse holder and replace
the fuse with a new one of proper amper-
age.
w
Be sure to use the specified fuse. An
incorrect fuse or a piece of wire may
allow excessive current flow. This could
cause electrical system damage and a fire
hazard.
NOTE:
If the new fuse blows again immediately,
consult a Yamaha dealer.
1 Fuse holder
2 Fuse (20A)
3 Spare fuse (20A)
