E
4-26
EML22110
Cleaning the Fuel Filter
1) Remove the screws holding the fuel
hose joint assembly . Pull the assem-
bly out of the tank.
2) Clean the filter (located on the end of
the suction pipe) in a suitable clean-
ing solvent. Allow the filter to dry.
3) Replace the gasket with a new one.
Reinstall the fuel hose joint assembly
and tighten the screws firmly.
604011
224012*
000606
EMU00831
INSPECTING AND REPLACING
ANODE(S)
Yamaha outboard motor is protected
from corrosion by a sacrificial anode(s).
Check the anode(s) periodically. Remove
the scales from surfaces of the anode(s).
For the inspection and replacement of the
internal anode(s), consult a Yamaha deal-
er.
cC
Do not paint the anode(s), for this would
render it ineffective.
