3-6
REMOTE CONTROL APPLICATIONS
704 REMOTE CONTROL SPACER
Designed to raise the control box 22 mm (0.9 in.) to make more clearance when the lever is into
WOT position.
6X3 REMOTE CONTROL
Designed for the electric start models. Best fitted to runabout type boats.
The mounting position can be selected from horizontal or inclined 30-degree up or down position
due to boat design.
* Ignition switch panel without engine shut-off cord and extension wire-harness are required to connect to the
engine.
* Throttle opening direction can be reversed.
* For further information, see the instruction (P/N: 6X3-28199-Y1) in the package.
Ref. No. Part No. Descriptions
1
704-48293-00 For STD single, Not shown
704-48293-20 For premium single
2 704-48293-30 For premium twin
Part No.
Throttle
PT/T
Mount
Remarks
Push
Pull R L
6X3-48206-01 1 1 1 With emergency shut-off cord
(1)
(2)
