3-26
REMOTE SWITCH TYPES AND APPLICATIONS
INDEPENDENT SWITCH PANEL
IG SWITCH W/ PANEL
To be continued.
Ref. No. Part No. Description
1 64D-82570-05 w/ bullet connectors for emergency stop SW
2 64D-82570-22 w/ 2P coupler for emergency stop SW, For 6X3 & 6X7 RC
3 6X6-82570-80 For Digital Network System (6Y9), 2nd station helm, Single engine application
4 6X6-82570-C0 For Digital Network System (6Y9), Multi engine application (All engine start/stop)
63 (2.48)
63 (2.48)
47 (1.85)
47 (1.85)
54 (2.12)5.6 (0.22)
63 (2.48)
63 (2.48)
47 (1.85)
47 (1.85)
54 (2.12)5.6 (0.22)
116.5 (4.59)
69.5 (2.74)9 (0.35)
P
R
B
G
Y
L
B
Y
G
R
B
Y
G
R
Br
W
140 (5.51)
355 (13.98)
B
To stop S/W
W
116.5 (4.59)
69.5 (2.74)
9 (0.35)
P
R
B
G
Y
L
Br
W
140 (5.51)
355 (13.98)
B W
To stop S/W
1
2
mm (in.)
mm (in.)
