6X4 MULTI-FUNCTION TILLER HANDLE
TILLER HANDLE KIT CONTENTS
90
KIT P/N:6X4-42102-41
70
KIT P/N:6X4-42102-52
Part name Part No. Q’ty Remarks
Cable clamp 63D-48538-00 2
Throttle cable 6H1-26301-01 1 610 mm (24 in.)
Shift cable 6H1-48321-11 1 726 mm (29 in.)
Ext. bracket (Short)
6X4-42121-00-8D
1 45 mm (1.8 in.)
Shift handle
6X4-44159-10-8D
1
Short type (exclusive), To replace original lever
Shift lever 6X4-44173-00 1
Screw 97780-60920 2
Bush 90386-26MA3 1
10-pin main harness 6X4-82586-30 1 700 mm (26 in.)
Stud bolt 90116-10031 2 M10-70 mm
Clamp 90464-09M42 1
Clamp 90464-15M11 1
Clamp 90465-13M36 2
Clip 90468-10005 2
Bolt 97595-08540 1
Friction shaft 66342-51800 1
Friction piece 66342-52800 1
Rod 69242-51501 1
Wing nut 90175-06003 1
locknut 90185-08057 2
Washer 92990-08600 2
Bolt 97080-06035 1
Part name Part No. Q’ty Remarks
Throttle cable 6H3-26301-01 1 530 mm (21 in.)
Shift cable 6H3-48321-11 1 610 mm (24 in.)
Cable clamp 63D-48538-00 2
Grommet 2 6H3-42725-30 1
Ext. bracket (Short)
6X4-42121-00-8D
1 45 mm (1.8 in.)
10-pin main harness 6X4-82586-30 1 600 mm (24 in.)
Stud bolt 90116-10031 2 M10-70 mm
locknut 90185-10027 2 M10
Clamp 90464-09M42 1
Clamp 90465-13M36 1
Clip 90468-10005 2
Friction shaft 66342-51800 1
Friction piece 66342-52800 1
Rod 69242-51501 1
Wing nut 90175-06003 1
locknut 90185-08057 2
Washer 92990-08600 2
Bolt 97080-06035 1
