4-10
6X4 MULTI-FUNCTION TILLER HANDLE
TILLER HANDLE KIT CONTENTS
50
KIT P/N:6X4-42102-63
Part name Part No. Q’ty Remarks
Stay 63D-24364-10 1
Fuel pipe clamp 2 63D-24367-00 1
Throttle cable 63D-26301-01 1 530 mm (21 in.)
Pipe 1 63D-42541-00 2
Nut 63D-42546-00 2
Shift cable 63D-48321-11 1 610 mm (24 in.)
Clamp 63D-48538-00 2
Clamp 63D-82361-00 1
Grommet 1 6H4-42724-20 1
10-pin main harness 6X4-82586-00 1 700 mm (26 in.)
Screw 90161-06M00 1 M6-25 mm
locknut 90185-10027 2 M10
Washer 90201-08M01 2
Collar 90387-06M26 1
Clamp 90464-09M42 1
Clamp 90465-13M36 1
Clip 90468-10005 2
Bolt 97595-06516 2
Bolt 97595-06535 1
Bolt 97595-08550 2
Friction plate 2 63D-42526-00 1
Friction plate 3 63D-42527-00 1
Friction piece 63D-42528-00 2
Steering lock knob 63D-42561-00 1
Steering lock shaft 63D-42562-00 1
Cover 68243-31801 1
locknut 90185-10M01 1
