5-40
6R3-85721-30 : 3 m (10 ft)
-50 : 5 m (16 ft) -80 : 8 m (26 ft)
Fuel tank
OUT
IN
OUT
IN
(*1)
(*2)
6Y5-83553-M0 :
2.5 m (8 ft)
688-82520-00
6Y5-85752-02
Speed hose (* 1)
688-8258A-50 : 5 m (16 ft)
-60 : 6 m (19 ft) -70 : 7 m (23 ft)
6K1-8258A-40 : 8 m (26 ft) 61B-8258A-00 : 9.5 m (32 ft)
6Y5-83553-F1 :
8 m (26 ft)
6Y5-83553-20 : 2.5 m (8 ft)
(* 1) Select either speedometer or GPS (NMEA0183) If GPS is connected, speed hose is not required. (* 2) Water separator (Market obtainable)
68F-82553-50 : 5 m (16 ft)
-60 : 6 m (19 ft) -70 : 7 m (23 ft) -80 : 8 m (26 ft) -90 : 9 m (29 ft) -A0 : 10.5 m (34 ft)
GPS
Remote
Oil Tank
Remote
Oil Tank
TACH
FUEL
TACH
Engine
Oil Tank
Engine
Oil Tank
NMEA
0183
SPEED
6Y5-85721-F0
SPEED
6Y5-87122-S0
6Y5-8350T-03
(+)
WIRING DIAGRAMS
DIGITAL METER (6Y5)
TWIN ENGINE W/ BINNACLE RC
250G/L250G
