6-14
Multi-sensor (OP)
FUEL TANK 2
FUEL TANK 1
(+)
(GND)
SPEEDFUELTACH(P)TACH(S)
P S
Coolant press. sensor (OP)
Speed sensor
ECM
Trim sensor
Coolant press. sensor (OP)
ECM
Trim sensor
Fuse (10A)
NMEA
0183
GPS
Fuel injected F30 – F/FL200
Immobilizer PWR distribution wire 1
Permanent power relay wire
Resistor
Resistor
Cap
Cap
Cap
Multi-hubMulti-hubMulti-hub
(* 1) Only one immobilizer is required.
(*1)
NETWORK WIRING DIAGRAMS
FUEL INJECTED F30-F250 [Mechanical RC] & HPDI ENGINES
TWIN ENGINE APPLICATION (Deluxe)
