1-49
OUTBOARD MOTOR DIMENSIONS
CLAMP BRACKET DIMENSIONS
Global model F75B F80B F90B F100D
US/CA model F75A F90A
PTT
Symbol mm (in.) Symbol mm (in.) Symbol mm (in.) Symbol mm (in.)
B1 125.4 (4.9) B8 — C1 — AN1 19 (0.75)
B2 254 (10.0) B9 18.5 (0.73) C2 — AN2 101.5 (4.0)
B3 163.5 (6.4) B10 — C3 80 (3.1)
B4 50.8 (2.0) B11 — D1 13 (0.51)
B5 180 (7.1) B12 — D2 55.5 (2.2)
B6 368 (14.5) B13 20 (0.79) D3 —
B7 — D4 —
B6
B3
B1
D1
B5
C/L
B3
B1
B5
C3
B13
B2
D2
D1
B4
B9
B9
B9
AN1
AN2 AN2
