Yamaha F6C - Crankcase

7-22
Crankcase
0
1
2
3
4
5
6
7
8
9
10
A
No. Part name Q’ty Remarks
18 Blind plug 1 M8  15 mm
19 Bolt 3 M6  35 mm
20 Drain bolt 1 M8  20 mm
21 Gasket 1 
22 Bolt 1 M8  20 mm
23 Oil seal housing 1
13
12
12
14
16
15
17
18
21
20
19
19
10
7
8
6
6
5
4
22
23
3
1
11
11
11
11
11
9
19
2
11
11
11
11
a
b
5 N·m (0.5 kgf·m, 3.7 ft·lb)
11 N·m (1.1 kgf·m, 8.1 ft·lb)
20 N·m (2.0 kgf·m, 14.8 ft·lb)
