@ Configuration memory
This message is transferred directly to the configuration
RAM specified by the memory No.
Status
ID No.
Sub-status
System No.
Message No.
Operation No
Memory No.
Byte count
Data
Check sum
EOX
11110000 (FOH)
01000011(43H)
01110101 (75H)
OOOOssss
00000000 (00H)
00000010 (02H)
OOOxxxxx
00000001 (01H)
00100000 (20H)
Oddddddd
1
Oddddddd
Oeeeeeee
11110111 (F7H)
Channel message
© MIDI channel specification (1 byte)
Status 11110000 (FOH)
ID No. 01000011 (43H)
Sub-status 0001 nnnn (n = channel No.)
Parameter group 00010101 (15H)
Parameter No. Oppppppp (p = 0~3FH)
Data Oddddddd
EOX 11110111 (F7H)
This message specifies MIDI channel and changes the
parameter. It also executes change of configuration data and
LFO related changes.
* Refer to Table 1 for the parameter No.
@ MIDI channel specification
(§) 16 configuration memory
All data of the configuration RAM.
Status
ID No.
Sub-status
System No.
Message No.
Operation No.
Memory No.
Byte count
Data
Check sum
EOX
11110000 (FOH)
01000011 (43H)
01110101 (75H)
OOOOssss
00000000 (00H)
00000011 (03H)
00000000 (00H)
00010100 (14H)
00000000 (00H)
Oddddddd
t
Oddddddd
Oeeeeeee
11110111 (F7H)
Status 11110000 (FOH)
ID No. 01000011 (43H)
Sub-status 0001 nnnn (n=channel No.)
Parameter group 00010101 (15H)
Parameter No. Oppppppp (p = 40H~7FH)
Data Oddddddd (Data Low)
OOOOdddd (Data High)
EOX 11110111 (F7H)
This message specifies MIDI channel and changes the voice
data.
* Refer to voice parameter list.
@ 1 voice bulk data
The voice data for one voice is set in the voice buffer of
the instrument specified by the instrument No.
Status
ID No.
Sub-status
System No.
Message No.
Operation No.
Byte count
Data
IIHOOOO(FOH)
0100001 K43H)
0111010K75H)
OOOOssss
00001 i i i (i = instrument No.)
OOOOOOOO(OOH)
OOOOOOOO(OOH)
00000001 (01H)
OOOOOOOO(OOH)
OOOOdddd(Data Low)
OOOOdddd(Data High)
Check sum
EOX
OOOOdddd (Data Low)
OOOOdddd (Data High)
Oeeeeeee
11110111 (F7H)
