Basic components
15
EMU26460
Flushing device
This device is used to clean the cooling wa-
ter passages of the motor using a garden
hose and tap water.
NOTE:
For details on usage, see page 41.
EMU26300
Warning indicator
If the engine develops a condition which is
cause for warning, the indicator lights up. For
details on how to read the warning indicator,
see page 18.
EMU26470
Tachometer
This gauge shows the engine speed and has
the following functions.
EMU26491
Digital tachometer
The tachometer shows the engine speed
and has the following functions.
NOTE:
All segments of the display will light momen-
tarily after the main switch is turned on and
will return to normal thereafter.
1. Top cowling lock lever(s)
1. Flushing device
1
ZMU04041
1
ZMU04042
1. Tachometer
2. Warning indicator(s)
ZMU04578
1
2
