Instrument and control functions
6-13
6
EAU62370
Fuel tank cap
To remove the fuel tank cap
1. Insert the key into main switch and
then turn it to “OPEN” position.
2. Push the “FUEL” button to open
the fuel tank cap.
To install the fuel tank cap
Push the fuel tank cap down into its
original position. A clicking sound can
be heard when the fuel tank cap is
locked.
EWA10132
Make sure that the fuel tank cap is
properly installed before riding.
Leaking fuel is a fire hazard.
1. Front wheel sensor
2. Front wheel sensor rotor
1. Fuel tank cap
1
1. Fuel tank cap
UB8BE0E0.book Page 13 Wednesday, April 11, 2018 9:35 AM
