Tilt Angle (HS8I/HS7I/HS5I only)
Wall mount
Ceiling mount
Model Bracket Maximum tilt angle
HS8I
BWS251-300 30°
BWS251-400 45°
BWS50-260 0°
BWS50-190 Not compatible
HS7I
BWS251-300 35°
BWS251-400 45°
BWS50-260 0°
BWS50-190 Not compatible
HS5I
BWS20-190 0°
BWS20-120 Not compatible
Model Bracket Maximum tilt angle
HS8I
BCS251 45°
BWS50-260
30°
BWS50-190
HS7I
BCS251 45°
BWS50-260
30°
BWS50-190
HS5I
BCS20-210
20°
BCS20-150
BWS20-190
BWS20-120
