1. Turn signal light bulb
3. Remove the burnt out bulb by
pushing it in and turning it coun-
terclockwise.
4. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
5. Install the turn signal light lens by
installing the screw.
6. Install the tail/brake light lens by
installing the screws. NOTICE:
Do not overtighten the screws,
otherwise the lens may break.
[ECA10681]
EAUS1151
Replacing the license plate
light bulb (Depends on
models)
1. Remove the lens by removing the
screw.
1. Screw
2. License plate light bulb socket
2. Remove the burnt out bulb by
pulling it out.
3. Insert a new bulb into the socket.
4. Install the lens by installing the
screw. NOTICE: Do not over-
tighten the screw, otherwise
the lens may break. [ECA11191]
EAUS1412
Replacing an auxiliary light
bulb
This model is equipped with two auxi-
liary lights. If an auxiliary light bulb
burns out, replace it as follows.
1. Remove cowling A. (See page
6-5).
2. Remove the auxiliary light socket
(together with the bulb) by pulling
it out.
1. Auxiliary light bulb socket
3. Remove the burnt-out bulb by
pulling it out.
To Next Page
