Trouble Recovery
101
1. Stop the engine.
2. Remove the top cowling.
3. Disconnect the water detection switch
coupler. NOTICE: Be careful not to get
any water on the water detection
switch coupler, otherwise a malfunc-
tion could occur.
[ECM01951]
4. Remove the cover.
5. Remove the hose holder, and then re-
move the fuel filter from its holder.
1. Water detection switch coupler
1. Cover
1. Holder
2. Fuel filter
U6EK30E0.book Page 101 Wednesday, January 29, 2014 4:03 PM
