Instruments and indicators
45
EMU36191
Start-up checks
Place the remote control lever / gear shift le-
ver in neutral and turn the main switch to “ ”
(on). After all the displays come on and the to-
tal hour display comes on, the gauge will
change to normal operation. If the buzzer
sounds and the water separator-alert indica-
tor blinks, consult your Yamaha dealer imme-
diately.
TIP:
To stop the buzzer, press the “ ” (set) or
“ ” (mode) button.
EMU38623
Yamaha Security System information
(if equipped)
Turn the main switch to the “ ” (on) position,
the currently selected Yamaha Security Sys-
tem mode (Lock / Unlock) will show on the
display.
Unlock mode
Lock mode
1. Set button
2. Mode button
1. Tachometer
2. Water detection-alert indicator
3. Engine trouble alert/maintenance indicator
4. Trim meter
5. Multifunction display
6. Battery voltage
7. Cooling water/engine temperature
8. Oil pressure (4-stroke models)
9. Cooling water pressure
10.YAMAHA SECURITY SYSTEM indicator
SET MODE
1 2
ZMU05417
110
9 8 7 6
2 3 4
5
ZMU05418
ZMU06457
SET MODE
ZMU06458
ZMU06459
