Yamaha MOTIF ES6 Software Manual

24
9 SYSTEM EFFECT settings
This section is explained in more detail in “System Effects” (page 30).
0 Keyboard
Click any key on the keyboard to monitor your edited voice in that key.
A KEY ASSIGN settings
Click on the left text box to select a Key Assign setting. Click on the right text box to select
Monophonic or Polyphonic. The “KEY ASSIGN” settings are not available for Drum Voices.
B MICRO TUNE settings
Click on the text box to select a Micro Tuning preset.
The “MICRO TUNE” settings are not available for Drum Voices.
C ASSIGNABLE 1/2 settings
Use the knobs to set the value of the parameter assigned to each of the assignable 1/2
controllers.
D MEQ GAIN CONTROL settings
Use the knobs to set the gain for each frequency band of the four-band EQ.
ELEMENT Unit
1 EL (Element) 1 to 4 buttons
Click these to open the corresponding “ELEMENT” dialogs.
n For Drum voices, you will see the following panel. Click [KEY C0...C6] to open the “Drum Key” dialog
(page 28).
23 41

Yamaha MOTIF ES6 Specifications

General

Keyboard	61 keys, Initial Touch/Aftertouch
Polyphony	128 notes
Display	240 x 64 dot backlit LCD
Wave ROM	175MB (when converted to 16-bit linear format)
Sequencer	16 Tracks, Approx. 226, 000 notes
Arpeggiator	1, 787 types
Connectors	MIDI In/Out/Thru, USB, Foot Controller, Foot Switch
Power Supply	AC Adaptor (PA-300 or an equivalent recommended by Yamaha)
Storage	SmartMedia
User Voices	128 normal voices + 32 drum kits
