Front Panel
21
Owner’s Manual
The Controls & Connectors
∞ SLOT 1-3 lamps Page 284
These three lamps show the installation status of the Plug-
in Boards.
If the Plug-in Board has been correctly installed, the
corresponding SLOT lamp will light.
n The Vocal Harmony Plug-in Board (PLG100-VH) can be installed
only to slot 1. It cannot be installed to slot 2 or 3.
n The Multi part Plug-in Board (PLG100-XG) can be installed only to
slot 3. It cannot be installed to slot 1 or 2.
§ BANK buttons Page 60
Each button selects a Voice or Performance Bank.
When the [CATEGORY SEARCH] button is turned on,
these buttons can be used to select the desired category
(printed below each button). When the [SECTION] button
is turned on in the Pattern mode, these buttons are used
to select the desired section.
¶ GROUP [A] - [H] buttons Page 48
Each button selects a Voice or Performance Group.
When the [CATEGORY SEARCH] button is turned on,
these buttons can be used to select the desired category
(printed below each button). When the [SECTION] button
is turned on in the Pattern mode, these buttons are used
to select the desired section.
• NUMBER [1] - [16] buttons Page 48
Use of these buttons differs depending on the on/off
status of the [TRACK SELECT] and [MUTE] buttons.
ª [CATEGORY SEARCH] button Page 62
When this button is turned on in the Performance mode,
the lower row of [BANK] buttons (labeled A.PIANO -
REED/PIPE below the buttons) and the [GROUP] buttons
can be used to select the Performance category.
When this button is turned on in another mode, the lower
row of [BANK] buttons (labeled A.PIANO - REED/PIPE
below the buttons) and the [GROUP] buttons can be used
to select the Voice category.
‚ [SECTION] button Page 57
When this button is turned on in the Pattern mode, the
GROUP [A] - [H] buttons can be used to select Pattern
Sections A - H and the [PRE5] - [PLG3] buttons of the
BANK buttons can be used to select Pattern Sections I - P.
⁄ [TRACK SELECT] button Page 58
Turning this button on in the Song/Pattern mode enables
the NUMBER [1] - [16] buttons for selecting
corresponding Song/Pattern tracks. The on/off status of
this button affects the NUMBER [1] - [16] buttons in
different ways, depending on the selected mode. (See •
“NUMBER [1] - [16] buttons” above.)
¤ [MUTE] button Page 58
Turning this button on in the Song/Pattern mode enables
the NUMBER [1] - [16] buttons for muting corresponding
Song/Pattern tracks.
Press one of the NUMBER [1] - [16] buttons while holding
this button to solo the corresponding track of the current
selected Song/Pattern.
The on/off status of this button affects the NUMBER [1] -
[16] buttons in different ways, depending on the selected
mode. (See • “NUMBER [1] - [16] buttons” above.)
Functions of the NUMBER [1] - [16] buttons
When [TRACK
SELECT] is on
When [MUTE]
is on
When both
[TRACK SELECT]
[MUTE] are off
Voice Play mode
Keyboard
transmit channel
setting
—
Voice selection,
according to Groups
A - H
Voice Edit mode
Element selection (1 - 4) and Element
Mute setting (9 - 12)
—
Performance
Play mode
Keyboard
transmit channel
setting
Performance part
Mute setting
(1 - 4)
Performance or
Voice selection
(if cursor is located
at Voice name),
according to Groups
A - H
Performance
Edit mode
Performance part
selection (1 - 4)
Master Play
mode
Keyboard transmit
channel setting
(when memorizing
the Voice mode or
Performance
mode to the
current Master) or
Song/Pattern track
selection (when
memorizing the
Song mode or
Pattern mode to
the current
Master)
—
Master selection,
according to Groups
A - H
Master Edit
mode
Zone selection
(1 - 4)
——
Song/Pattern
Play mode
Song/Pattern
track selection
Song/Pattern
track Mute
setting
Song/Pattern
selection, according
to Groups A - H
Song/Pattern
Mixing mode
Song/Pattern part
selection
Song/Pattern part
Mute setting
Mixing Voice
Edit mode
Element selection (1- 4) and Element
Mute setting (9- 12)
—
To Next Page
