Reference Song Mode
Song Job mode
230
Owner’s Manual
04: Extract Event
This Job moves all instances of specified event data from a specified range of a track to the same range in a
different track.
TR (Track)
001 : 1 : 000 - 999 : 4 : 479
Determines the track (01 - 16) and range of measures/beats/clocks over which the Job is applied.
EventType Selects the event type to be extracted. Specific note and control change numbers can also be specified as required.
Settings: Note, PC (Program Change), PB (Pitch Bend), CC (Control Change), CAT (Channel Aftertouch), PAT (Polyphonic Aftertouch),
EXC (System Exclusive)
→ TR Determines the destination track (01 - 16).
05: Create Continuous Data
This Job creates continuous pitch bend or control change data over the specified range.
TR (Track)
001 : 1 : 000 - 999 : 4 : 479
Determines the track (01 - 16, TMP, all) and range of measures/beats/clocks over which the Job is applied.
EventType Determines the event type to be created.
Settings: PB (Pitch Bend), CC (Control Change)*, CAT (Channel Aftertouch), EXC (System Exclusive), TMP (Tempo)
* You can also specify the CC No. (Control Change number).
Data (Data Range) Determines the lower and upper limits for the data range to be created. The left value is the lower limit, and the right
value is the upper limit.
Settings: When Event Type is set to PB: -8192~+8191
When Event Type is set to TMP: 1.0~300.0
When Event Type is set to other: 0~127
Clock Determines the number of clocks to be inserted between each created event.
Settings: 001~999
Curve Determines the “curve” of the continuous data.
Refer to the graph for approximate curve shapes.
Settings: -16 ~+16
NumberOfTimes Determines the number of times the data creation is to be repeated.
For example, if data is created in the range M001:1:000 ~ M003:1:000 and this parameter is set to 03, the same data
will be created at M003:1:000 ~ M005:1:000 and M005:1:000 ~ M007:1:000. This Job lets you insert continuous
volume or filter cutoff variations to create tremolo or wah effects.
Settings: 01~99
06: Thin Out
This Job thins out the specified type of continuous data in the specified range — allowing you to free up memory
space for other data or further recording.
TR (Track)
001 : 1 : 000 - 999 : 4 : 479
Determines the track (01 - 16, TMP, all) and range of measures/beats/clocks over which the Job is applied.
EventType Determines the event type to be thinned.
Settings: PB (Pitch Bend), CC (Control Change)*, CAT (Channel Aftertouch), PAT (Polyphonic Aftertouch), TMP (Tempo)
* You can also specify the CC No. (Control Change number).
n The Thin Out Job will not work on continuous data that has a clock interval of greater than 60 clocks per event.
07: Modify Control Data
This Job lets you change the values of a specified type of control change data — pitch bend, control change,
aftertouch, etc. — in the specified range. Data changes are calculated as follows:
Modified value = (original value x Rate) + Offset.
The modified value cannot exceed the minimum/maximum limits of the parameter. Any result lower than the minimum
is set to the minimum; any result higher than the maximum is set to the maximum.
TR (Track)
001 : 1 : 000 - 999 : 4 : 479
Determines the track (01 - 16, TMP, all) and range of measures/beats/clocks over which the Job is applied.
EventType Determines the event type to be modified.
Settings: PB (Pitch Bend), CC (Control Change)*, CAT (Channel Aftertouch), PAT (Polyphonic Aftertouch), TMP (Tempo)
* You can also specify the CC No. (Control Change number).
SetAll Sets all target events to the same fixed value. When set to “off,” the Set All parameter has no effect. When set to a
value other than “off,” the Rate and Offset parameters are unavailable and appear as “***” on the display.
Settings: off, 000 ~127 (-8192 ~ +8191 for pitch bend, 0.1 ~ 300.0 for tempo)
Rate Determines the percentage by which the target events will be shifted from their original values. When the Set All
parameter (above) is set to something other than “off,” this parameter appears as “***” and cannot be changed.
Settings: 000% ~ 200%, ***
Offset Adds a fixed value to the Rate-adjusted event values. When the Set All parameter (above) is set to something other
than “off,” this parameter appears as “***” and cannot be changed.
Settings: -127~127 (-8192 ~ +8191 for pitch bend, -275 ~ +275 for tempo), ***
Curve = +16 Curve = 0 (linear) Curve = -16
Start point
End point
This distance specified by Clock
