Yamaha MOTIF ES6 User Manual

Quick Guide — Advanced Course
Editing a Performance
90
Owner’s Manual
Editing a Performance by using the Knobs
The four knobs at the top left of the instrument are not only for tweaking the sound while you perform — you can also use
them to edit a Performance, either in the Performance Play mode or the Performance Edit mode.
● When the [PAN/SEND] indicator is turned on:
● When the [TONE] indicator is turned on:
n The settings above are applied as offsets to the AEG and FEG settings in the Performance Edit mode.
● When the [ARP FX] indicator is turned on:
● When the [EQ] indicator is turned on:
n The settings above are applied as offsets to the EQ settings in the [PERFORM] → Performance selection → [EDIT] → [COMMON] → [F2] OUT/MEF
→ [SF2] MEQ (Master EQ) display.
● When both the [PAN/SEND] and [TONE] indicators are turned on (by pressing them simultaneously):
n In addition to above functions, Master Effect related parameters (set in the [PERFORM] → Performance selection → [COMMON] → [F2] OUT/MEF
→ [SF3] MEF display) can be assigned to these four knobs by pressing the [ARP FX] and [EQ] buttons simultaneously. The particular parameters
are assigned to the four knobs can be set in the [UTILITY] → [F4] CTL ASN → [SF5] MEF display.
PAN Determines the stereo pan position of the Performance. [PERFORM] → Performance selection → [EDIT] → [COMMON]
→ [F2] OUT/MEF → [SF1] OUT → Pan
Page 213
REVERB Determines the amount of Reverb effect that is applied to the
Performance.
[PERFORM] → Performance selection → [EDIT] → [COMMON]
→ [F2] OUT/MEF → [SF1] OUT → RevSend
Page 213
CHORUS Determines the amount of Chorus effect that is applied to the
Performance.
[PERFORM] → Performance selection → [EDIT] → [COMMON]
→ [F2] OUT/MEF → [SF1] OUT → ChoSend
Page 213
TEMPO Determines the tempo of the Arpeggio assigned to the currently selected
Performance.
[PERFORM] → Performance selection → [F6] ARP → Tempo Page 213
CUTOFF Raises or lowers the Filter cutoff frequency to adjust the tone brilliance. [PERFORM] → Performance selection → [F5] EG → CUTOF Page 213
RESONANCE Boosts or attenuates the level at the area around the Filter cutoff
frequency.
[PERFORM] → Performance selection → [F5] EG → RESO Page 213
ATTACK Determines the attack time of the sound. For example, you can adjust a
strings Voice so that the sound gradually swells in volume by setting a
slow attack time – simply turn this knob to the right.
[PERFORM] → Performance selection → [F5] EG → ATK (AEG) Page 213
RELEASE
Determines the release time of the sound. Turning the knob to the right sets a
long release time and (depending on the Voice assigned to the selected
Performance) lets the sound sustain after the key is released. To produce a
sharp release, in which the sound abruptly cuts off, set a short release time.
[PERFORM] → Performance selection → [F5] EG → REL (AEG) Page 213
SWING Adjusts the swing feel of the Arpeggio playback. [PERFORM] → Performance selection → [EDIT] → [COMMON]
→ [F3] ARP → [SF3] PLAY FX → Swing
Page 214
GATE TIME Adjusts the Gate Time (length) of the Arpeggio notes. [PERFORM] → Performance selection → [EDIT] → [COMMON]
→ [F3] ARP → [SF3] PLAY FX → GateTimeRate
Page 214
VELOCITY Adjusts the velocity of the Arpeggio notes. [PERFORM] → Performance selection → [EDIT] → [COMMON]
→ [F3] ARP → [SF3] PLAY FX → VelocityRate
Page 214
UNITMULTIPLY Adjusts the Arpeggio playback time based on tempo. [PERFORM] → Performance selection → [EDIT] → [COMMON]
→ [F3] ARP → [SF3] PLAY FX → UnitMultiply
Page 214
LO Determines the amount of boost or attenuation applied to the low
frequency band of the Master EQ.
[PERFORM] → Performance selection → [EDIT] → [COMMON]
→ [F1] GENERAL → [SF3] MEQ OFS → LOW
Page 213
LO MID Determines the amount of boost or attenuation applied to the low-
midrange frequency band of the Master EQ.
[PERFORM] → Performance selection → [EDIT] → [COMMON]
→ [F1] GENERAL → [SF3] MEQ OFS → LOW MID
Page 213
HI MID Determines the amount of boost or attenuation applied to the high-
midrange frequency band of the Master EQ.
[PERFORM] → Performance selection → [EDIT] → [COMMON]
→ [F1] GENERAL → [SF3] MEQ OFS → HIGH MID
Page 213
HI Determines the amount of boost or attenuation applied to the high
frequency band of the Master EQ.
[PERFORM] → Performance selection → [EDIT] → [COMMON]
→ [F1] GENERAL → [SF3] MEQ OFS → HIGH
Page 213
ASSIGN A Adjusts parameters assigned to these knobs in the [UTILITY] → [F4] CTL ASN → [SF2] ASSIGN display. Page 263
ASSIGN B
ASSIGN 1 Depends on the settings of the Voice assigned to the selected Performance. Page 192
ASSIGN 2
TIP
