MOX6/MOX8 Data List
104
Bank Select
MIDI Data Table
Available Bank Select/Program Change
When only the Program Change is received after entering any of the mode, the
corresponding voice in the currently selected Type/Memory is called up.
The Master number and the Performance/Song/Pattern/Voice mode can be changed only
via the Parameter Change.
The Song/Pattern can be changed only via the Song Select (Song: F3, 00 – F3, 3F / Pattern:
F3, 00 – F3, 3F).
In the Performance mode, the Part Voice cannot be changed via the Program Change.
MSB (HEX) LSB (HEX) Program No. Type Memory Description
0 00 0 00 0 – 127 Normal Voice GM Voice
127 7F 0 00 0 Drum Voice GM Drum
63 3F 0 00 0 – 127 Normal Voice Preset 1
1 01 0 – 127 Preset 2
2 02 0 – 127 Preset 3
3 03 0 – 127 Preset 4
4 04 0 – 127 Preset 5
5 05 0 – 127 Preset 6
6 06 0 – 127 Preset 7
7 07 0 – 127 Preset 8
8 08 0 – 127 User 1
9 09 0 – 127 User 2
10 0A 0 – 127 User 3
32 20 0 – 63 Drum Voice Preset
40 28 0 – 31 User
60 3C 0 – 15 Mixing Voice User Can be selected in the Song/
Pattern mode.
63 3F 64 40 0 – 127 Performance User 1
65 41 0 – 127 User 2
Parameter Block Settings
Top Address
High Mid Low
SYSTEM 00 00 00 System
00 03 00 Insertion A for Voice A/D
00 04 00 Insertion B for Voice A/D
00 05 00 Sequencer Setup
00 06 00 Remote
00 20 00 Master EQ for Voice
00 21 00 Master Effect for Voice
00 4n 00 Audio Part (A/D)
00 5n 00 Quick Setup
00 6n 00 Quick Setup Config Audio
00 7n 00 Quick Setup Config MIDI
MODE CHANGE 0A 00 00 Mode Change
PART SET CONTROL for MIX VOICE 0D 00 00 Part Set Control for Mix Voice
BULK CONTROL 0E 00 00 Header
0F 00 00 Footer
MULTIPLE BULK CONTROL 10 00 00 Header
11 00 00 Footer
MASTER KEYBOARD 33 00 00 Common
32 nn 00 Zone 1 – 4 (nn: 00 – 03)
PERFORMANCE COMMON 30 00 00 Common
30 01 00 Reverb
30 02 00 Chorus
30 03 00 Insertion A for A/D
30 04 00 Insertion B for A/D
30 10 00 Master EQ
30 11 00 Master Effect
30 30 00 Arpeggio Common
PERFORMANCE PART 31 pp 00 Part 1 – 4 (pp: 00 – 03)
34 pp 00 Arpeggio Part 1 – 4 (pp: 00 – 03)
35 4n 00 Audio Part (A/D)
SONG/PATTERN COMMON 36 00 00 Common
36 01 00 Reverb
36 02 00 Chorus
36 03 00 Insertion A for A/D
36 04 00 Insertion B for A/D
36 10 00 Master EQ
36 11 00 Master Effect
36 30 00 Arpeggio Common
SONG/PATTERN PART 37 pp 00 Part 1 – 16 (pp: 00 – 0F)
38 pp 00 Arpeggio Part 1 – 16 (pp: 00 – 0F)
39 4n 00 Audio Part (A/D)
NORMAL VOICE COMMON 40 00 00 Common
40 01 00 Reverb
40 02 00 Chorus
40 03 00 Insertion A
40 04 00 Insertion B
40 05 00 Insertion L
40 06 00 Controller+LFO
40 30 00 Arpeggio
NORMAL VOICE ELEMENT GROUP 1 41 ee 00 Element Group 1 (ee: 00 – 07)
NORMAL VOICE ELEMENT GROUP 2 42 ee 00 Element Group 2 (ee: 00 – 07)
DRUM COMMON 46 00 00 Common
46 01 00 Reverb
46 02 00 Chorus
46 03 00 Insertion A
46 04 00 Insertion B
46 05 00 Insertion L
46 08 00 Controller
46 30 00 Arpeggio
DRUM ELEMENT GROUP 47 ee 00 Element Group (ee: 0 – 72)
