MOX6/MOX8 Data List
126
MIDI Data Table
TOTAL SIZE = 46 2E (HEX)
ee = element number (00 – 48: C0 – C6)
Address Size Data Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
47 ee 00 1 00 – 01 Element Switch off, on 01
01 1 reserved
02 2 00 – 14
01 – 6E
Wave Number 1 – 2670 0D
62
04 1 00 – 01 Receive Note Off off, on 00
05 1 00 – 01 Key Assign Mode single, multi 01
06 1 00 – 7F Alternate Group 0: off, 1 – 127 00
07 1 01 – 7F Pan L63 – C – R63 40
08 1 00 – 7F Random Pan Depth 0 – 127 00
09 1 00 – 7F Alternate Pan Depth L64 – 0 – R63 40
0A 1 00 – 7F Reverb Send Level 0 – 127 5A
0B 1 00 – 7F Chorus Send Level 0 – 127 00
0C 1 00 – 02 Insertion Effect thru, insA, insB 00
0D 1 reserved
47 ee 0E 1 00 – 7F Element Level 0 – 127 7F
0F 1 00 – 7F Level Velocity Sensitivity -64 – +63 40
10 1 reserved
11 1 00 – 7F AEG Attack Time 0 – 127 00
12 1 00 – 7F AEG Decay 1 Time 0 – 127 60
13 1 00 – 7F AEG Decay 2 Time 0 – 126, hold 50
14 1 reserved
15 1 reserved
16 1 reserved
17 1 00 – 7F AEG Decay 1 Level 0 – 127 7F
18 1 reserved
19 1 reserved
47 ee 1A 1 10 – 70 Coarse Tune -48 – +48 40
1B 1 00 – 7F Fine Tune -64 – +63 40
1C 1 00 – 7F Pitch Velocity Sensitivity -64 – +63 40
1D 1 reserved
47 ee 1E 2 00 – 01
00 – 7F
LPF Cutoff Frequency 0 – 255 01
7F
20 1 00 – 7F LPF Cutoff Velocity
Sensitivity
-64 – +63 40
21 1 00 – 7F LPF Resonance 0 – 127 00
22 2 00 – 01
00 – 7F
HPF Cutoff Frequency 0 – 255 00
00
24 1 00 – 05 EQ Type 2 Band, P.EQ, Boost6,
Boost12, Boost18,
thru
00
25 1 00 – 1F EQ Q 0 – 31 (0.7 – 10.3) 00
26 2 00 – 01
2E – 7B
EQ 1 Frequency 2 Band: 46 – 182,
P.EQ: 83 – 251
00
36
28 1 20 – 60 EQ 1 GAIN -32 – +32 40
29 1 reserved
2A 2 01 – 01
03 – 71
EQ 2 Frequency 2 Band: 131 – 241 01
67
2C 1 20 – 60 EQ 2 GAIN -32 – +32 40
2D 1 reserved
MIDI PARAMETER CHANGE TABLE
(DRUM VOICE KEY)
To Next Page
