MOX6/MOX8 Data List
79
Effect Parameter List
Reverb Block
[0] NO EFFECT
When this type is selected, no parameters are available.
[1] REV-X HALL
[4] REV-X ROOM
REV-X HALL: (Table No.23)
REV-X ROOM: (Table No.24)
For details, refer to the Effect Data Assign Table.
[2] R3 HALL
[3] SPX HALL
[5] R3 ROOM
[6] SPX ROOM
[7] R3 PLATE
[8] SPX STAGE
[9] SPACE SIMULATOR
Chorus, Insertion Block
[0] THRU/NO EFFECT
When this type is selected, no parameters are available.
Category — REVERB
[1] SPX HALL
[2] SPX ROOM
[3] SPX STAGE
Category — DELAY
[1] CROSS DELAY
[2] TEMPO CROSS DELAY
[3] TEMPO DELAY MONO
No. Parameter Range Value
Table No.
1 Reverb Time 0.3s – 18.0s (HALL)/ 10.0s
(ROOM)
(0 – 69) 23/24
2 Diffusion 0 – 10 (0 – 10)
3 Initial Delay 0.1ms – 200.0ms (0 – 127) 5
4 HPF Cutoff Frequency 20Hz – 8.0kHz (0 – 52) 3
5 LPF Cutoff Frequency 1.0kHz – 20.0kHz (34 – 60) 3
6 Room Size 0 – 31 (0 – 31)
7 High Ratio 0.1 – 1.0 (1 – 10)
8 Low Ratio 0.1 – 1.4 (1 – 14)
9 Decay 0 – 63 (0 – 63)
10 —
11 —
12 —
13 —
14 —
15 —
16 —
No. Parameter Range Value
Table No.
1 Reverb Time 0.3s – 30.0s (0 – 69) 4
2 Diffusion 0 – 10 (0 – 10)
3 Initial Delay 0.1ms – 200.0ms (0 – 127) 5
4 HPF Cutoff Frequency 20Hz – 8.0kHz (0 – 52) 3
5 LPF Cutoff Frequency 1.0kHz – 20.0kHz (34 – 60) 3
6—
7—
8—
9—
10 —
11 Reverb Delay 0.1ms – 200.0ms (0 – 127) 5
12 Density 0 – 4 (0 – 4)
13 ER/Rev Balance E63>R – E=R – E<R63 (1 – 127)
14 Feedback High Damp 0.1 – 1.0 (1 – 10)
15 Feedback Level -63 – +63 (1 – 127)
16 —
No. Parameter Range Value
Table No.
1 Reverb Time 0.3s – 30.0s (0 – 69) 4
2 Diffusion 0 – 10 (0 – 10)
3 Initial Delay 0.1ms – 200.0ms (0 – 127) 5
4 HPF Cutoff Frequency 20Hz – 8.0kHz (0 – 52) 3
5 LPF Cutoff Frequency 1.0kHz – 20.0kHz (34 – 60) 3
6 Width 0.5m – 30.2m (0 – 104) 11
7 Height 0.5m – 30.2m (0 – 104) 11
8 Depth 0.5m – 30.2m (0 – 104) 11
9 Wall Vary 0 – 30 (0 – 30)
10 —
11 Reverb Delay 0.1ms – 200.0ms (0 – 127) 5
12 Density 0 – 4 (0 – 4)
13 ER/Rev Balance E63>R – E=R – E<R63 (1 – 127)
14 Feedback High Damp 0.1 – 1.0 (1 – 10)
15 Feedback Level -63 – +63 (1 – 127)
16 Space Type 0 – 1 (0 – 1)
No. Parameter Range Value
Table No.
1 Reverb Time 0.3s – 30.0s (0 – 69) 4
2 Diffusion 0 – 10 (0 – 10)
3 Initial Delay 0.1ms – 99.3ms (0 – 63) 5
4 HPF Cutoff Frequency 20Hz – 8.0kHz (0 – 52) 3
5 LPF Cutoff Frequency 1.0kHz – 20.0kHz (34 – 60) 3
6—
7—
8—
9—
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 Reverb Delay 0.1ms – 99.3ms (0 – 63) 5
12 Density 0 – 4 (0 – 4)
13 ER/Rev Balance E63>R – E=R – E<R63 (1 – 127)
14 Feedback High Damp 0.1 – 1.0 (1 – 10)
15 Feedback Level -63 – +63 (1 – 127)
16 —
No. Parameter Range Value
Table No.
1 Delay Time L>R 0.1ms – 1638.3ms (1 – 16383)
2 Delay Time R>L 0.1ms – 1638.3ms (1 – 16383)
3 Feedback Level -63 – +63 (1 – 127)
4 Input Select L, R, L&R (0 – 2)
5 Feedback High Damp 0.1 – 1.0 (1 – 10)
6—
7—
8—
9—
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 —
12 —
13 EQ Low Frequency 32Hz – 2.0kHz (4 – 40) 3
14 EQ Low Gain -12dB – +12dB (52 – 76)
15 EQ High Frequency 500Hz – 16.0kHz (28 – 58) 3
16 EQ High Gain -12dB – +12dB (52 – 76)
No. Parameter Range Value
Table No.
1 Delay Time L>R 32nd/3 – 4thx6 (0 – 19) 13
2 Delay Time R>L 32nd/3 – 4thx6 (0 – 19) 13
3 Feedback Level -63 – +63 (1 – 127)
4 Input Select L, R, L&R (0 – 2)
5 Feedback High Dump 0.1 – 1.0 (1 – 10)
6 Lag -63ms – +63ms (1 – 127)
7—
8—
9—
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 —
12 —
13 – 16: Same as the parameters shaded in gray in CROSS DELAY above.
No. Parameter Range Value
Table No.
1 Delay Time 32nd/3 – 4thx6 (0 – 19) 13
2 Feedback Level -63 – +63 (1 – 127)
3 Feedback High Dump 0.1 – 1.0 (1 – 10)
4 L/R Diffusion -63ms – +63ms (1 – 127)
5 Lag -63ms – +63ms (1 – 127)
6—
7—
8—
9—
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 —
12 —
13 – 16: Same as the parameters shaded in gray in CROSS DELAY above.
