Yamaha MOX8 Data List

MOX6/MOX8 Data List
80
Effect Parameter List
[4] TEMPO DELAY STEREO
[5] CONTROL DELAY
[6] DELAY L, R
[7] DELAY L, C, R
[8] DELAY L, R (STEREO)
Category — CHORUS
[1] G CHORUS
[2] 2 MODULATOR
[3] SPX CHORUS
No. Parameter Range Value Table No.
1 Delay Time 32nd/3 – 4thx6 (0 – 19) 13
2 Feedback Level -63 – +63 (1 – 127)
3 Feedback High Dump 0.1 – 1.0 (1 – 10)
4 L/R Diffusion -63ms – +63ms (1 – 127)
5 Lag -63ms – +63ms (1 – 127)
6—
7—
8—
9—
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 —
12 —
13 – 16: Same as the parameters shaded in gray in CROSS DELAY on page 79.
No. Parameter Range Value Table No.
1 Delay Time 0.1ms – 1486.0ms (1 – 14860)
2 Delay transition rate 1 – 48 (1 – 48)
3 Feedback Level -63 – +63 (1 – 127)
4 Feedback High Damp 0.1 – 1.0 (1 – 10)
5—
6 – 9: Same as the parameters shaded in gray in CROSS DELAY on page 79.
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 Control Type Normal, Scratch (0 – 1)
12 —
13 —
14 —
15 —
16 —
No. Parameter Range Value Table No.
1 Delay Time L 0.1ms – 1638.3ms (1 – 16383)
2 Delay Time R 0.1ms – 1638.3ms (1 – 16383)
3 Feedback Time 1 0.1ms – 1638.3ms (1 – 16383)
4 Feedback Time 2 0.1ms – 1638.3ms (1 – 16383)
5 Feedback Level -63 – +63 (1 – 127)
6 Feedback High Damp 0.1 – 1.0 (1 – 10)
7—
8—
9—
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 —
12 —
13 – 16: Same as the parameters shaded in gray in CROSS DELAY on page 79.
No. Parameter Range Value Table No.
1 Delay Time L 0.1ms_1638.3ms (1 – 16383)
2 Delay Time R 0.1ms_1638.3ms (1 – 16383)
3 Delay Time C 0.1ms_1638.3ms (1 – 16383)
4 Feedback Time 0.1ms_1638.3ms (1 – 16383)
5 Feedback Level -63 – +63 (1 – 127)
6 Delay Level C 0 – 127 (0 – 127)
7 Feedback High Damp 0.1 – 1.0 (1 – 10)
8—
9—
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 —
12 —
13 – 16: Same as the parameters shaded in gray in CROSS DELAY on page 79.
No. Parameter Range Value Table No.
1 Delay Time L 0.1ms – 1638.3ms (1 – 16383)
2 Delay Time R 0.1ms – 1638.3ms (1 – 16383)
3 Feedback Time L 0.1ms – 1638.3ms (1 – 16383)
4 Feedback Time R 0.1ms – 1638.3ms (1 – 16383)
5 Feedback Level -63 – +63 (1 – 127)
6 Feedback High Damp 0.1 – 1.0 (1 – 10)
7—
8—
9—
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 —
15 —
13 – 16: Same as the parameters shaded in gray in CROSS DELAY on page 79.
No. Parameter Range Value Table No.
1 LFO Speed 0.0Hz – 39.70Hz (0 – 127) 1
2—
3 PM Depth 0 – 127 (0 – 127)
4 Feedback Level -63 – +63 (1 – 127)
5 Delay Offset 0.0ms – 50.0ms (0 – 127) 2
6 – 9: Same as the parameters shaded in gray in CROSS DELAY on page 79.
10 Dry / Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 EQ Mid Frequency 100Hz – 10.0kHz (14 – 54) 3
12 EQ Mid Gain -12dB – +12dB (52 – 76)
13 EQ Mid Width 0.1 – 12.0 (1 – 120)
14 —
15 Input Mode Mono, Stereo (0 – 1)
16 —
No. Parameter Range Value Table No.
1 LFO Speed 0.0Hz – 39.70Hz (0 – 127) 1
2 AM Depth 0 – 127 (0 – 127)
3 PM Depth 0 – 127 (0 – 127)
4 Feedback Level -63 – +63 (1 – 127)
5 Delay Offset 0.0ms – 50.0ms (0 – 127) 2
6 – 9: Same as the parameters shaded in gray in CROSS DELAY on page 79.
10 Dry / Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 EQ Mid Frequency 100Hz – 10.0kHz (14 – 54) 3
12 EQ Mid Gain -12dB – +12dB (52 – 76)
13 EQ Mid Width 0.1 – 12.0 (1 – 120)
14 —
15 Input Mode Mono, Stereo (0 – 1)
16 —
No. Parameter Range Value Table No.
1 LFO Speed 0.0Hz – 39.70Hz (0 – 127) 1
2 LFO Depth 0 – 127 (0 – 127)
3 Feedback Level -63 – +63 (1 – 127)
4 Delay Offset 0.0ms – 50.0ms (0 – 127) 2
5—
6 – 9: Same as the parameters shaded in gray in CROSS DELAY on page 79.
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 EQ Mid Frequency 100Hz – 10.0kHz (14 – 54) 3
12 EQ Mid Gain -12dB – +12dB (52 – 76)
13 EQ Mid Width 0.1 – 12.0 (1 – 120)
14 —
15 Input Mode Mono, Stereo (0 – 1)
16 —

Yamaha MOX8 Specifications

General

Polyphony	64 notes
Arpeggiator	6, 720 types
Display	240 x 64 dot LCD
Sound Engine	AWM2
Multitimbral Capacity	16 parts
Wave ROM	355MB (when converted to 16-bit linear format)
Keyboard	88-key, Graded Hammer Standard (GHS) keyboard
Effects	Reverb, Chorus, Insertion Effects, Master Effects, EQ
Sequencer	16-track
Connectivity	USB, MIDI In/Out, Phones, Output L/Mono, R, Foot Controller, Footswitch, Damper
Dimensions	1, 320 x 405 x 168 mm
