MOX6/MOX8 Data List
123
MIDI Data Table
TOTAL SIZE = 72 48 (HEX)
Address Size Data Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
46 00 00 1 00, 20 – 7E Voice Name 1 0, 32..126 (ASCII) I
01 1 00, 20 – 7E Voice Name 2 0, 32..126 (ASCII) n
02 1 00, 20 – 7E Voice Name 3 0, 32..126 (ASCII) i
03 1 00, 20 – 7E Voice Name 4 0, 32..126 (ASCII) t
04 1 00, 20 – 7E Voice Name 5 0, 32..126 (ASCII) i
05 1 00, 20 – 7E Voice Name 6 0, 32..126 (ASCII) a
06 1 00, 20 – 7E Voice Name 7 0, 32..126 (ASCII) l
07 1 00, 20 – 7E Voice Name 8 0, 32..126 (ASCII) i
08 1 00, 20 – 7E Voice Name 9 0, 32..126 (ASCII) z
09 1 00, 20 – 7E Voice Name 10 0, 32..126 (ASCII) e
0A 1 00, 20 – 7E Voice Name 11 0, 32..126 (ASCII) d
0B 1 00, 20 – 7E Voice Name 12 0, 32..126 (ASCII)
0C 1 00, 20 – 7E Voice Name 13 0, 32..126 (ASCII) V
0D 1 00, 20 – 7E Voice Name 14 0, 32..126 (ASCII) o
0E 1 00, 20 – 7E Voice Name 15 0, 32..126 (ASCII) i
0F 1 00, 20 – 7E Voice Name 16 0, 32..126 (ASCII) c
10 1 00, 20 – 7E Voice Name 17 0, 32..126 (ASCII) e
11 1 00, 20 – 7E Voice Name 18 0, 32..126 (ASCII)
12 1 00, 20 – 7E Voice Name 19 0, 32..126 (ASCII)
13 1 00, 20 – 7E Voice Name 20 0, 32..126 (ASCII)
14 1 reserved
15 1 reserved
16 1 reserved
17 1 reserved
18 1 00 – 11 Voice Category (Main) 0..17 11
(NoAsg)
Refer to
the Voice
category
list.
19 1 00 – 05 Voice Category (Sub) 0..5 00 (--) Refer to
the Voice
category
list.
1A 1 reserved
1B 1 reserved
1C 1 reserved
1D 1 reserved
46 00 1E 1 00 – 22 Knob Function Select bit0-3 KnobUp:
0=Tone1, 1=Tone2,
2=Tone3
bit4-7 KnobLo: 0=EQ,
1=Fx, 2=Arp
00
1F 1 01 – 7F Pan L63..C..R63 40
20 1 reserved
21 1 00 – 7F AEG Attack Time -64..+63 40
22 1 00 – 7F AEG Decay Time -64..+63 40
23 1 reserved
24 1 reserved
25 1 reserved
26 1 reserved
27 1 reserved
28 1 reserved
29 1 reserved
2A 1 00 – 7F Cutoff Frequency -64..+63 40
2B 1 00 – 7F Resonance -64..+63 40
2C 2 00 – 01
2E – 36
EQ Low Frequency 50.1 – 2.00k 00
36
2E 1 20 – 60 EQ Low Gain -32 – +32 (-12.00db –
+12.00db)
40
2F 1 reserved
30 2 00 – 01
53 – 71
EQ Mid Frequency 139.7 – 10.1k 01
0D
32 1 20 – 60 EQ Mid Gain -32 – +32 (-12.00db –
+12.00db)
40
33 1 00 – 1F EQ Mid Q 0 – 31 (0.7 – 10.3) 00
34 2 01 – 01
03 – 7F
EQ High Frequency 503.8 – 14.0k 01
67
36 1 20 – 60 EQ High Gain -32 – +32 (-12.00db –
+12.00db)
40
37 1 reserved
38 1 00 – 7F Assignable Knob 1 Value -64..+63 40
39 1 00 – 7F Assignable Knob 2 Value -64..+63 40
3A 1 00 – 01 Assignable Function 1
Mode
momentary, latch 01
3B 1 00 – 01 Assignable Function 2
Mode
momentary, latch 01
3C 1 reserved
3D 1 reserved
3E 1 reserved
46 00 3F 1 00 – 7F Volume 0 – 127 7F
40 1 reserved
41 1 10 – 58 Pitch Bend Range Upper -48 – +24 [semitones] 42
42 1 10 – 58 Pitch Bend Range Lower -48 – +24 [semitones] 3E
43 1 00 – 7F Reverb Send 0 – 127 00
44 1 00 – 7F Chorus Send 0 – 127 00
46 00 45 1 00 – 03 Insertion Connect Type parallel, ins A>B, ins
B>A, vocoder
01
46 1 00 – 7F Ins-EF Reverb Send Level 0 – 127 00
47 1 00 – 7F Ins-EF Chorus Send Level 0 – 127 00
Address Size Data Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
46 30 00 1 00 – 05 ARP SF Select SF1 ~ SF6 00
01 1 reserved
02 2 00 – 02
05 – 2C
ARP Tempo 5..300 00
5A
04 1 reserved
05 1 reserved
06 2 reserved
08 2 reserved
0A 2 reserved
0C 2 reserved
0E 1 00 – 01 ARP Switch off, on
0F 1 reserved
10 1 reserved
11 1 reserved
12 1 reserved
13 1 reserved
14 1 00 – 01 ARP Loop off, on 01
15 1 00 – 02 ARP Hold sync-off, off, on 01
16 1 00 – 06 ARP Unit Multiply 50%, 66%, 75%,
100%, 133%, 150%,
200%
03
17 1 00 – 7F ARP Note Limit Low C-2..G8 00
18 1 00 – 7F ARP Note Limit High C-2..G8 7F
19 1 01 – 7F ARP Velocity Limit Low 1 – 127 01
1A 1 01 – 7F ARP Velocity Limit High 1 – 127 7F
1B 1 00 – 04 ARP Key Mode sort, thru, direct,
sort+direct,
thru+direct
00
1C 1 00 – 01 ARP Velocity Mode original, thru 00
1D 1 00 – 01 ARP Change Timing realtime, measure 01
1E 1 01 – 07 ARP Quantize Value 32th, 16th_Triplet,
16th, 8th_Triplet, 8th,
4th_Triplet, 4th
03
1F 1 00 – 64 ARP Quantize Strength 0...100% 00
20 2 00 – 01
00 – 48
ARP Velocity Rate 0...200% 00
64
22 2 00 – 01
00 – 48
ARP Gate Time Rate 0...200% 00
64
24 1 reserved
25 1 reserved
26 1 reserved
27 1 reserved
28 2 00 – 01
08 – 78
ARP Swing -120 … 0 … +120 01
00
2A 1 00 – 7F ARP Accent Velocity
Threshold
off,1 … 127 40
2B 1 00 – 01 ARP Accent Start
Quantize
off, on 01
2C 1 3D – 43 ARP Octave Range -3 … 0 … +3 40
2D 1 36 – 4A ARP Output Octave Shift -10 … 0 … +10 40
2E 1 00 – 01 ARP Trigger Mode gate, toggle 00
2F 1 00 – 01 ARP Random SFX off, on 01
30 1 00 – 01 ARP Random SFX Key on
Control
off, on 01
31 1 00 – 7F ARP Random SFX Velocity
Offset
-64 … 0 … +63 40
32 2 00 – 01
1C – 64
ARP Assign Velocity Rate
Offset SF1
-100 … 0 … +100 01
00
34 2 00 – 01
1C – 64
ARP Assign Gate Time
Offset SF1
-100 … 0 … +100 01
00
36 2 00 – 01
1C – 64
ARP Assign Velocity Rate
Offset SF2
-100 … 0 … +100 01
00
38 2 00 – 01
1C – 64
ARP Assign Gate Time
Offset SF2
-100 … 0 … +100 01
00
3A 2 00 – 01
1C – 64
ARP Assign Velocity Rate
Offset SF3
-100 … 0 … +100 01
00
3C 2 00 – 01
1C – 64
ARP Assign Gate Time
Offset SF3
-100 … 0 … +100 01
00
3E 2 00 – 01
1C – 64
ARP Assign Velocity Rate
Offset SF4
-100 … 0 … +100 01
00
40 2 00 – 01
1C – 64
ARP Assign Gate Time
Offset SF4
-100 … 0 … +100 01
00
42 2 00 – 01
1C – 64
ARP Assign Velocity Rate
Offset SF5
-100 … 0 … +100 01
00
44 2 00 – 01
1C – 64
ARP Assign Gate Time
Offset SF5
-100 … 0 … +100 01
00
46 2 00 – 01
1C – 64
ARP Assign Velocity Rate
Offset SF6
-100 … 0 … +100 01
00
48 2 00 – 01
1C – 64
ARP Assign Gate Time
Offset SF6
-100 … 0 … +100 01
00
4A 2 00 – 34
00 – 7B
40 – 41
00 – 7F
ARP SF1 Assign Type off,
Preset 0001 … 6779,
User 001 … 256
04
6E
MA_Pf
Arp1
Address Size Data Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
MIDI PARAMETER CHANGE TABLE
(DRUM VOICE COMMON)
