MOX6/MOX8 Data List
122
MIDI Data Table
TOTAL SIZE = 88 58 (HEX)
ee = element number 00 – 07
TOTAL SIZE = 74 4A (HEX)
ee = element number 00 – 07
3D 1 00 – 7F Random Pitch Depth 0 – 127 00
3E 1 00 – 7F Pitch Key Follow Sensitivity -200% – +200% 60
3F 1 00 – 7F Pitch Key Follow Sensitivity
Center Key
C -2 – G8 3C
40 1 00 – 7F Pitch Fine Scaling Sensitivity -64 – +63 40
41 1 00 – 7F PEG Hold Time 0 – 127 00
42 1 00 – 7F PEG Attack Time 0 – 127 28
43 1 00 – 7F PEG Decay 1 Time 0 – 127 40
44 1 00 – 7F PEG Decay 2 Time 0 – 127 40
45 1 00 – 7F PEG Release Time 0 – 127 40
46 2 00 – 01
00 – 7F
PEG Hold Level -128 – +127 (-4800 –
+4800 [cent])
01
00
48 2 00 – 01
00 – 7F
PEG Attack Level -128 – +127 (-4800 –
+4800 [cent])
01
00
4A 2 00 – 01
00 – 7F
PEG Decay 1 Level -128 – +127 (-4800 –
+4800 [cent])
01
00
4C 2 00 – 01
00 – 7F
PEG Decay 2 Level -128 – +127 (-4800 –
+4800 [cent])
01
00
4E 2 00 – 01
00 – 7F
PEG Release Level -128 – +127 (-4800 –
+4800 [cent])
01
00
50 1 00 – 7F PEG Depth -64 – +63 54
51 1 00 – 04 PEG Time Velocity Sensitivity
Segment
ATK , ATK + DCY, DCY,
ATK+RLS, ALL
04
52 1 00 – 7F PEG Time Velocity Sensitivity -64 – +63 40
53 1 00 – 7F PEG Depth Velocity
Sensitivity
-64 – +63 40
54 1 00 – 04 PEG Depth Velocity
Sensitivity Curve
00 – 04 02
55 1 00 – 7F PEG Time Key Follow
Sensitivity
-64 – +63 40
56 1 00 – 7F PEG Time Key Follow
Sensitivity Center Key
C-2 – G8 3C
57 1 reserved
Address Size Data
Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
42 ee 00 1 00 – 15 Filter Type LPF24D, LPF24A,
LPF18, LPF18s,
LPF12+HPF12,
LPF6+HPF12,
HPF24D, HPF12,
BPF12D, BPFw,
BPF6, BEF12, BEF6,
DualLPF, DualHPF,
DualBPF, DualBEF,
LPF12+BPF6, THRU
04
01 1 reserved
02 2 00 – 01
00 – 7F
Filter Cutoff Frequency 0 – 255 01
20
04 1 00 – 7F Filter Cutoff Velocity
Sensitivity
-64 – +63 40
05 1 00 – 7F Filter Resonance/Width/
Band
0 – 127 00
06 1 00 – 7F Filter Resonance Velocity
Sensitivity
-64 – +63 40
07 1 reserved
08 2 00 – 01
00 – 7F
HPF Cutoff Frequency 0 – 255 00
00
0A 2 00 – 01
00 – 7F
Distance -128 – +127
(available only when
the dual type filter is
set.)
01
00
0C 2 00 – 01
00 – 7F
Filter Gain 0 – 255 01
66
0E 1 00 – 7F FEG Hold Time 0 – 127 00
0F 1 00 – 7F FEG Attack Time 0 – 127 00
10 1 00 – 7F FEG Decay 1 Time 0 – 127 40
11 1 00 – 7F FEG Decay 2 Time 0 – 127 40
12 1 00 – 7F FEG Release Time 0 – 127 50
13 1 reserved
14 2 00 – 01
00 – 7F
FEG Hold Level -128 – +127 (-9600 –
+9600 [cent])
01
00
16 2 00 – 01
00 – 7F
FEG Attack Level -128 – +127 (-9600 –
+9600 [cent])
01
7F
18 2 00 – 01
00 – 7F
FEG Decay 1 Level -128 – +127 (-9600 –
+9600 [cent])
01
7F
1A 2 00 – 01
00 – 7F
FEG Decay 2 Level -128 – +127 (-9600 –
+9600 [cent])
01
7F
1C 2 00 – 01
00 – 7F
FEG Release Level -128 – +127 (-9600 –
+9600 [cent])
01
00
1E 1 00 – 7F FEG Depth -64 – +63 68
1F 1 00 – 04 FEG Time Velocity Sensitivity
Segment
ATK , ATK + DCY, DCY,
ATK+RLS, ALL
04
20 1 00 – 7F FEG Time Velocity Sensitivity -64 – +63 40
21 1 00 – 7F FEG Depth Velocity
Sensitivity
-64 – +63 40
22 1 00 – 04 FEG Depth Velocity
Sensitivity Curve
00 – 04 02
Address Size Data
Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
23 1 00 – 7F FEG Time Key Follow
Sensitivity
-64 – +63 40
24 1 00 – 7F FEG Time Key Follow
Sensitivity Center Key
C -2 – G8 18
25 1 00 – 7C Filter Cutoff Scaling Break
Point 1
C -2 – E8 24 BP1<BP2<
BP3<BP4
26 1 01 – 7D Filter Cutoff Scaling Break
Point 2
C#-2 – F8 30 BP1<BP2<
BP3<BP4
27 1 02 – 7E Filter Cutoff Scaling Break
Point 3
D -2 – F#8 3C BP1<BP2<
BP3<BP4
28 1 03 – 7F Filter Cutoff Scaling Break
Point 4
D#-2 – G8 48 BP1<BP2<
BP3<BP4
29 1 reserved
2A 2 00 – 01
00 – 7F
Filter Cutoff Scaling Offset 1 -128 – +127 01
00
2C 2 00 – 01
00 – 7F
Filter Cutoff Scaling Offset 2 -128 – +127 01
00
2E 2 00 – 01
00 – 7F
Filter Cutoff Scaling Offset 3 -128 – +127 01
00
30 2 00 – 01
00 – 7F
Filter Cutoff Scaling Offset 4 -128 – +127 01
00
32 1 00 – 7F Filter Cutoff Key Follow
Sensitivity
-200% – +200% 4A
33 1 00 – 7F HPF Cutoff Key Follow
Sensitivity
-200% – +200% 40
42 ee 34 1 00 – 05 EQ Type 2 Band, P.EQ, Boost6,
Boost12, Boost18,
thru
00
35 1 00 – 1F EQ Q 0 – 31 (0.7 – 10.3) 00
36 2 00 – 01
2E – 7B
EQ 1 Frequency 2 Band: 46 – 182,
P.EQ: 83 – 251
00
36
38 1 20 – 60 EQ 1 Gain -32 – +32 40
39 1 reserved
3A 2 01 – 01
03 – 71
EQ 2 Frequency 2 Band: 131 – 241 01
67
3C 1 20 – 60 EQ 2 Gain -32 – +32 40
3D 1 reserved
42 ee 3E 1 00 – 02 LFO Wave saw, tri, squ 01
3F 1 00 – 01 LFO Key On Reset off, on 01
40 1 00 – 7F LFO Key On Delay Time 0 – 127 00
41 1 00 – 3F LFO Speed 0 – 63 26
42 1 00 – 7F LFO AMod Depth 0 – 127 00
43 1 00 – 7F LFO PMod Depth 0 – 127 00
44 1 00 – 7F LFO FMod Depth 0 – 127 00
45 1 00 – 7F LFO Fade In Time 0 – 127 00
42 ee 46 1 00 – 05 Common LFO Phase Offset +0, +90, +120, +180,
+240, +270
00
47 1 00 – 7F Common LFO Box 1 Depth
Ratio
0 – 127 7F
48 1 00 – 7F Common LFO Box 2 Depth
Ratio
0 – 127 7F
49 1 00 – 7F Common LFO Box 3 Depth
Ratio
0 – 127 7F
Address Size Data
Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
To Next Page
