MOX6/MOX8 Data List
121
MIDI Data Table
TOTAL SIZE = 60 3C (HEX)
24 1 00 – 45 LFO Set 1 Destination Refer to the “LFO Box
Destination” of the
Control List.
02
25 1 00 – 7F LFO Set 2 Depth 0 – 127 00
26 1 00 – 45 LFO Set 2 Destination Refer to the “LFO Box
Destination” of the
Control List.
04
27 1 00 – 7F LFO Set 3 Depth 0 – 127 00
28 1 00 – 45 LFO Set 3 Destination Refer to the “LFO Box
Destination” of the
Control List.
04
29 1 00 – 06 User Wave Total Step 2, 3, 4, 6, 8, 12, 16 06
2A 1 00 – 03 User Wave Slope off, up, down,
up&down
00
2B 1 00 – 7F User Wave Step Value 1 0 – 127 40
2C 1 00 – 7F User Wave Step Value 2 0 – 127 40
2D 1 00 – 7F User Wave Step Value 3 0 – 127 40
2E 1 00 – 7F User Wave Step Value 4 0 – 127 40
2F 1 00 – 7F User Wave Step Value 5 0 – 127 40
30 1 00 – 7F User Wave Step Value 6 0 – 127 40
31 1 00 – 7F User Wave Step Value 7 0 – 127 40
32 1 00 – 7F User Wave Step Value 8 0 – 127 40
33 1 00 – 7F User Wave Step Value 9 0 – 127 40
34 1 00 – 7F User Wave Step Value 10 0 – 127 40
35 1 00 – 7F User Wave Step Value 11 0 – 127 40
36 1 00 – 7F User Wave Step Value 12 0 – 127 40
37 1 00 – 7F User Wave Step Value 13 0 – 127 40
38 1 00 – 7F User Wave Step Value 14 0 – 127 40
39 1 00 – 7F User Wave Step Value 15 0 – 127 40
3A 1 00 – 7F User Wave Step Value 16 0 – 127 40
3B 1 00 – 7F LFO Random Speed
Depth
0 – 127 00
Address Size Data Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
Address Size Data
Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
41 ee 00 1 00 – 01 Element Switch off, on 01 (only
EL1)
01 1 reserved
02 2 00 – 14
01 – 6E
Wave Number 1 – 2670 00
01
04 1 00 – 07 Element Group Number 1 – 8 00
05 1 01 – 7F Pan L63 – C – R63 40
06 1 00 – 7F Random Pan Depth 0 – 127 00
07 1 00 – 7F Alternate Pan Depth L64 – 0 – R63 40
08 1 00 – 7F Scaling Pan Depth -64 – +63 40
09 1 00 – 07 XA Control normal, legato, key off
sound, wave cycle,
wave random, all AF
off, AF 1 on, AF 2 on
00
0A 1 00 – 7F Note Limit Low 0 – 127 00
0B 1 00 – 7F Note Limit High 0 – 127 7F
0C 1 01 – 7F Velocity Limit Low 1 – 127 01
0D 1 01 – 7F Velocity Limit High 1 – 127 7F
0E 1 00 – 7F Velocity Cross Fade 0 – 127 00
0F 1 00 – 7F Key On Delay 0 – 127 (available
only when the Tempo
Sync is set to off.)
00
10 1 00 – 01 Key On Delay Tempo Sync off, on 00
11 1 00 – 02 Insertion Effect thru, insA, insB 01
12 2 00 – 00
00 – 3F
Controller Set Element Sw 1st bit6-0: reserved
2nd bit6: reserved
2nd bit5: off, on set 6
2nd bit4: off, on set 5
2nd bit3: off, on set 4
2nd bit2: off, on set 3
2nd bit1: off, on set 2
2nd bit0: off, on set 1
00
3F
14 2 00 – 00
00 – 07
LFO Set Element Sw 1st bit6-0: reserved
2nd bit6-3: reserved
2nd bit2: off, on box 3
2nd bit1: off, on box 2
2nd bit0: off, on box 1
00
07
16 1 05 – 15 Key On Delay Tempo 16th, 8th/3, 16th., 8th,
4th/3, 8th., 4th, 2th/3,
4th., 2nd, Whole/3,
2nd., 4thX4, 4thX5,
4thX6, 4thX7, 4thX8
0B This is
available
only when
Temp o
Sync is set
to off.
17 1 00 – 01 Half Damper Switch off, on 00
18 1 reserved
19 1 reserved
41 ee 1A 1 00 – 7F Element Level 0 – 127 7F
1B 1 00 – 7F Level Velocity Sensitivity -64 – +63 40
1C 1 00 – 7F Level Velocity Sensitivity
Offset
0 – 127 00
1D 1 00 – 04 Level Velocity Sensitivity
Curve
00 – 04 03
1E 1 00 – 7F AEG Attack Time 0 – 127 00
1F 1 00 – 7F AEG Decay 1 Time 0 – 127 40
20 1 00 – 7F AEG Decay 2 Time 0 – 127 40
21 1 00 – 7F Half Damper Time 0 – 127 7F
22 1 00 – 7F AEG Release Time 0 – 127 32
23 1 00 – 7F AEG Init Level 0 – 127 00
24 1 00 – 7F AEG Attack Level 0 – 127 7F
25 1 00 – 7F AEG Decay 1 Level 0 – 127 7F
26 1 00 – 7F AEG Decay 2 Level 0 – 127 7F
27 1 reserved
28 1 00 – 04 AEG Time Velocity Segment ATK, ATK+DCY, DCY,
ATK+RLS, ALL
04
29 1 00 – 7F AEG Time Velocity Sensitivity -64 – +63 40
2A 1 00 – 7F AEG Time Key Follow
Sensitivity
-64 – +63 40
2B 1 00 – 7F AEG Time Key Follow Center
Key
C -2 – G8 18
2C 1 00 – 7C Level Scaling Break Point 1 C -2 – E8 24 BP1<BP2<
BP3<BP4
2D 1 01 – 7D Level Scaling Break Point 2 C#-2 – F8 30 BP1<BP2<
BP3<BP4
2E 1 02 – 7E Level Scaling Break Point 3 D -2 – F#8 3C BP1<BP2<
BP3<BP4
2F 1 03 – 7F Level Scaling Break Point 4 D#-2 – G8 48 BP1<BP2<
BP3<BP4
30 2 00 – 01
00 – 7F
Level Scaling Offset 1 -128 – +127 01 00
32 2 00 – 01
00 – 7F
Level Scaling Offset 2 -128 – +127 01 00
34 2 00 – 01
00 – 7F
Level Scaling Offset 3 -128 – +127 01 00
36 2 00 – 01
00 – 7F
Level Scaling Offset 4 -128 – +127 01 00
38 1 00 – 7F Level Key Follow Sensitivity -200% – +200% 40
39 1 00 – 7F AEG Time Key Follow
Sensitivity Release
Adjustment
-64 – +63 40
3A 1 10 – 70 Coarse Tune -48 – +48 40
3B 1 00 – 7F Fine Tune -64 – +63 40
3C 1 00 – 7F Pitch Velocity Sensitivity -64 – +63 40
MIDI PARAMETER CHANGE TABLE
(NORMAL VOICE ELEMENT)
