MOX6/MOX8 Data List
114
MIDI Data Table
TOTAL SIZE = 80 50 (HEX)
TOTAL SIZE = 14 0E (HEX)
TOTAL SIZE = 38 26 (HEX)
Address Size Data
Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
36 00 00 1 reserved
01 1 reserved
02 1 reserved
03 1 reserved
04 1 reserved
05 1 reserved
06 1 reserved
07 1 reserved
08 1 reserved
09 1 reserved
0A 1 reserved
0B 1 reserved
0C 1 reserved
0D 1 reserved
0E 1 reserved
0F 1 reserved
10 1 reserved
11 1 reserved
12 1 reserved
13 1 reserved
14 1 reserved
15 1 reserved
16 1 reserved
17 1 reserved
18 1 reserved
19 1 reserved
1A 1 reserved
1B 1 reserved
1C 1 reserved
1D 1 reserved
36 00 1E 1 00 – 22 Knob Function Select bit0-3 KnobUp:
0=Tone1, 1=Tone2,
2=Tone3
bit4-7 KnobLo: 0=EQ,
1=Fx, 2=Arp
00
1F 1 reserved
20 1 reserved
21 1 reserved
22 1 reserved
23 1 reserved
24 1 reserved
25 1 reserved
26 1 reserved
27 1 reserved
28 1 reserved
29 1 reserved
2A 1 reserved
2B 1 reserved
2C 1 reserved
2D 1 reserved
2E 1 reserved
2F 1 reserved
30 1 reserved
31 1 reserved
32 1 reserved
33 1 reserved
34 1 reserved
35 1 reserved
36 1 reserved
37 1 reserved
38 1 reserved
39 1 reserved
3A 1 reserved
3B 1 reserved
3C 1 reserved
36 00 3D 1 reserved
3E 1 reserved
3F 1 00 – 01 Assignable Switch 1 Mode momentary, latch 01
40 1 00 – 01 Assignable Switch 2 Mode momentary, latch 01
41 1 reserved
42 1 reserved
43 1 reserved
44 1 reserved
45 1 reserved
46 1 reserved
47 1 reserved
48 1 reserved
49 1 reserved
4A 1 reserved
4B 1 01 – 02 A/D Input Insertion Connect
Typ e
ins A>B, ins B>A 01
4C 4 00 – 00
00 – 23
00 – 00
00 – 00
Insertion Part Sw 1st bit6-0: reserved
2nd bit6: reserved
2nd bit5: off, on A/D
Part reserved
2nd bit4: reserved
2nd bit3: reserved
2nd bit2: reserved
2nd bit1: off, on Part 16
2nd bit0: off, on Part 15
3rd bit6: off, on Part 14
3rd bit5: off, on Part 13
3rd bit4: off, on Part 12
3rd bit3: off, on Part 11
3rd bit2: off, on Part 10
3rd bit1: off, on Part 9
3rd bit0: off, on Part 8
4th bit6: off, on Part 7
4th bit5: off, on Part 6
4th bit4: off, on Part 5
4th bit3: off, on Part 4
4th bit2: off, on Part 3
4th bit1: off, on Part 2
4th bit0: off, on Part 1
00
00
00
07
Up to
three
parts can
be turned
on simul-
taneously.
Address Size Data Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
36 30 00 1 00 – 05 ARP SF Select SF1 ~ SF6 00
01 1 reserved
02 2 reserved
04 1 00 – 01 ARP Common Switch off, on 00
05 1 00 – 07 ARP Sync Quantize Value off, 32th, 16th_Triplet,
16th, 8th_Triplet, 8th,
4th_Triplet, 4th
00
06 2 00 – 01
1C – 64
ARP Quantize Strength
Offset
-100 … +100 01
00
08 2 00 – 01
1C – 64
ARP Gate Time Rate
Offset
-100 … +100 01
00
0A 2 00 – 01
1C – 64
ARP Velocity Rate Offset -100 … +100 01
00
0C 2 00 -01
08 – 78
ARP Swing Offset -120 … +120 01
00
Address Size Data Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
36 01 00 2 00 – 7F
00 – 7F
Reverb Type Refer to the “Effect
Type List.”
01
00
Rev-X Hall
02 1 00 – 7F Preset Number 00 Basic
03 1 reserved
04 2 00 – 7F
00 – 7F
Reverb Parameter 1 Refer to the “Effect
Parameter List.”
Init value for Rev-X
Hall / Basic
06 2 00 – 7F
00 – 7F
Reverb Parameter 2 : Init value for Rev-X
Hall / Basic
08 2 00 – 7F
00 – 7F
Reverb Parameter 3 : Init value for Rev-X
Hall / Basic
0A 2 00 – 7F
00 – 7F
Reverb Parameter 4 : Init value for Rev-X
Hall / Basic
0C 2 00 – 7F
00 – 7F
Reverb Parameter 5 : Init value for Rev-X
Hall / Basic
0E 2 00 – 7F
00 – 7F
Reverb Parameter 6 : Init value for Rev-X
Hall / Basic
10 2 00 – 7F
00 – 7F
Reverb Parameter 7 : Init value for Rev-X
Hall / Basic
12 2 00 – 7F
00 – 7F
Reverb Parameter 8 : Init value for Rev-X
Hall / Basic
14 2 00 – 7F
00 – 7F
Reverb Parameter 9 : Init value for Rev-X
Hall / Basic
16 2 00 – 7F
00 – 7F
Reverb Parameter 10 : Init value for Rev-X
Hall / Basic
18 2 00 – 7F
00 – 7F
Reverb Parameter 11 : Init value for Rev-X
Hall / Basic
1A 2 00 – 7F
00 – 7F
Reverb Parameter 12 : Init value for Rev-X
Hall / Basic
1C 2 00 – 7F
00 – 7F
Reverb Parameter 13 : Init value for Rev-X
Hall / Basic
1E 2 00 – 7F
00 – 7F
Reverb Parameter 14 : Init value for Rev-X
Hall / Basic
20 2 00 – 7F
00 – 7F
Reverb Parameter 15 : Init value for Rev-X
Hall / Basic
22 2 00 – 7F
00 – 7F
Reverb Parameter 16 : Init value for Rev-X
Hall / Basic
24 1 00 – 7F Reverb Return -∞dB…0dB…+6dB
(0…96…127)
40
25 1 01 – 7F Reverb Pan L63…C…R63 40
Address Size Data
Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
MIDI PARAMETER CHANGE TABLE
(SONG/PATTERN COMMON)
