MOX6/MOX8 Data List
116
MIDI Data Table
TOTAL SIZE = 38 26 (HEX)
Address Size Data Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
36 11 00 2 00 – 7F
00 – 7F
Master Effect Type Refer to the “Effect
Type List.”
08
20
Multi Band
Comp
02 1 00 – 7F Preset Number 00 Basic
03 1 reserved
04 2 00 – 7F
00 – 7F
Master Effect Parameter 1 Refer to the “Effect
Parameter List.”
Init value for Multi
Band Comp / Basic
06 2 00 – 7F
00 – 7F
Master Effect Parameter 2 : Init value for Multi
Band Comp / Basic
08 2 00 – 7F
00 – 7F
Master Effect Parameter 3 : Init value for Multi
Band Comp / Basic
0A 2 00 – 7F
00 – 7F
Master Effect Parameter 4 : Init value for Multi
Band Comp / Basic
0C 2 00 – 7F
00 – 7F
Master Effect Parameter 5 : Init value for Multi
Band Comp / Basic
0E 2 00 – 7F
00 – 7F
Master Effect Parameter 6 : Init value for Multi
Band Comp / Basic
10 2 00 – 7F
00 – 7F
Master Effect Parameter 7 : Init value for Multi
Band Comp / Basic
12 2 00 – 7F
00 – 7F
Master Effect Parameter 8 : Init value for Multi
Band Comp / Basic
14 2 00 – 7F
00 – 7F
Master Effect Parameter 9 : Init value for Multi
Band Comp / Basic
16 2 00 – 7F
00 – 7F
Master Effect Parameter 10 : Init value for Multi
Band Comp / Basic
18 2 00 – 7F
00 – 7F
Master Effect Parameter 11 : Init value for Multi
Band Comp / Basic
1A 2 00 – 7F
00 – 7F
Master Effect Parameter 12 : Init value for Multi
Band Comp / Basic
1C 2 00 – 7F
00 – 7F
Master Effect Parameter 13 : Init value for Multi
Band Comp / Basic
1E 2 00 – 7F
00 – 7F
Master Effect Parameter 14 : Init value for Multi
Band Comp / Basic
20 2 00 – 7F
00 – 7F
Master Effect Parameter 15 : Init value for Multi
Band Comp / Basic
22 2 00 – 7F
00 – 7F
Master Effect Parameter 16 : Init value for Multi
Band Comp / Basic
24 1 00 – 01 Master Effect Switch off, on 00
25 1 reserved
Address Size Data
Range
(HEX)
Parameter Name Settings Default
(HEX)
Notes
High Mid Low
37 pp 00 1 reserved
01 1 00 – 7F Bank Select MSB 0 – 127 3F
02 1 00 – 7F Bank Select LSB 0 – 127 00
03 1 00 – 7F Program Number 1 – 128 00
04 1 00 – 0F,
7F
Receive Channel 1..16, off (7F) Part No.
05 1 00 – 01 Mono/Poly mono, poly 01
06 1 01 – 7F Velocity Limit Low 1 – 127 01
07 1 01 – 7F Velocity Limit High 1 – 127 7F
08 1 00 – 7F Note Limit Low C-2 – G8 00
09 1 00 – 7F Note Limit High C-2 – G8 7F
0A 1 10 – 58 Pitch Bend Range Upper -48 – +24 42
0B 1 10 – 58 Pitch Bend Range Lower -48 – +24 3E
0C 1 00 – 7F Velocity Sensitivity Depth 0 – 127 40
0D 1 00 – 7F Velocity Sensitivity Offset 0 – 127 40
0E 1 00 – 7F Volume 0 – 127 64
0F 1 01 – 7F Pan L63 – C – R63 40
10 2 00 – 0F
00 – 0F
Detune -12.8 – +12.7 [Hz]
1st bit3-0  bit7-4,
2nd bit3-0  bit3-0
08
00
(80)
12 1 00 – 7F Reverb Send 0 – 127 0C
13 1 00 – 7F Chorus Send 0 – 127 00
14 1 reserved
15 1 00 – 7F Dry Level 0 – 127 7F
16 1 28 – 58 Note Shift -24 – +24 [semitones] 40
17 1 reserved
18 1 00 – 01 Param. with Voice off, on 00
19 1 00 – 01 Voice with Arp off, on 00
1A 1 00 – 01 Portamento Switch off, on 00
1B 1 00 – 7F Portamento Time 0 – 127 40
1C 1 00 – 01 Portamento Mode fingered, fulltime 01
1D 1 reserved
1E 1 00 – 01 USB Audio Output Select USB 1/2, USB 3/4 01 This is
available
only when
the audio
connect
mode is
set to 2
Stereo Rec
mode.
37 pp 1F 1 18 – 7C Receive PB
Receive AT
Receive Program Change
Receive Bank Select
Receive Control Change
reserved
bit6: off, on PB
bit5: off, on AT
bit4: off, on Program
Change
bit3: off, on Bank
Select
bit2: off, on Control
Change
bit1-0: reserved
7C
20 1 02 – 6F Receive FC2
Receive FC1
reserved
Receive MW
Receive Sustain/Sostenuto
Receive Pan
Receive Volume/Expression
bit6: off, on FC2
bit5: off, on FC1
bit4: reserved
bit3: off, on MW
bit2: off, on Sustain/
Sostenuto
bit1: off, on Pan
bit0: off, on Volume/
Expression
6F
21 1 00 – 7F Receive Assignable Switch 2
Receive Assignable Switch 1
Receive Assignable Knob 2
Receive Assignable Knob 1
Receive RB
Receive BC
Receive FS
bit6: off, on ASW2
bit5: off, on ASW1
bit4: off, on AKN2
bit3: off, on AKN1
bit2: off, on RB
bit1: off, on BC
bit0: off, on FS
7F
37 pp 22 1 00 – 01 Voice Element Pan off, on 01
23 1 00 – 7F AEG Attack Time -64 – +63 40
24 1 00 – 7F AEG Decay Time -64 – +63 40
25 1 00 – 7F AEG Sustain Level -64 – +63 40 Only for
Normal
Voice
26 1 00 – 7F AEG Release Time -64 – +63 40 Only for
Normal
Voice
27 1 00 – 7F FEG Attack Time -64 – +63 40 Only for
Normal
Voice
28 1 00 – 7F FEG Decay Time -64 – +63 40 Only for
Normal
Voice
29 1 00 – 7F FEG Sustain Level -64 – +63 40 Only for
Normal
Voice
2A 1 00 – 7F FEG Release Time -64 – +63 40 Only for
Normal
Voice
2B 1 00 – 7F FEG Depth -64 – +63 40 Only for
Normal
Voice
2C 1 reserved
2D 1 00 – 7F Filter Cutoff Frequency -64 – +63 40
2E 1 00 – 7F Filter Resonance/Width -64 – +63 40
37 pp 2F 1 reserved
MIDI PARAMETER CHANGE TABLE
(SONG/PATTERN PART)

Yamaha MOX8 Specifications

General

Polyphony	64 notes
Arpeggiator	6, 720 types
Display	240 x 64 dot LCD
Sound Engine	AWM2
Multitimbral Capacity	16 parts
Wave ROM	355MB (when converted to 16-bit linear format)
Keyboard	88-key, Graded Hammer Standard (GHS) keyboard
Effects	Reverb, Chorus, Insertion Effects, Master Effects, EQ
Sequencer	16-track
Connectivity	USB, MIDI In/Out, Phones, Output L/Mono, R, Foot Controller, Footswitch, Damper
Dimensions	1, 320 x 405 x 168 mm
