Instrument and control functions
5-37
1
2
3
4
5
6
7
8
9
10
11
12
EAU15306
Sidestand
The sidestand is located on the left side
of the frame. Raise the sidestand or
lower it with your foot while holding the
vehicle upright.
TIP
The built-in sidestand switch is part of
the ignition circuit cut-off system, which
cuts the ignition in certain situations.
(See the following section for an expla-
nation of the ignition circuit cut-off sys-
tem.)
WARNING
EWA10242
The vehicle must not be ridden with
the sidestand down, or if the sides-
tand cannot be properly moved up
(or does not stay up), otherwise the
sidestand could contact the ground
and distract the operator, resulting
in a possible loss of control.
Yamaha’s ignition circuit cut-off
system has been designed to assist
the operator in fulfilling the respon-
sibility of raising the sidestand be-
fore starting off. Therefore, check
this system regularly and have a
Yamaha dealer repair it if it does not
function properly.
EAU57950
Ignition circuit cut-off system
The ignition circuit cut-off system (com-
prising the sidestand switch, clutch
switch and neutral switch) has the fol-
lowing functions.
 It prevents starting when the trans-
mission is in gear and the sides-
tand is up, but the clutch lever is
not pulled.
 It prevents starting when the trans-
mission is in gear and the clutch le-
ver is pulled, but the sidestand is
still down.
 It cuts the running engine when the
transmission is in gear and the sid-
estand is moved down.
Periodically check the operation of the
ignition circuit cut-off system according
to the following procedure.
BW8-9-20_1.book 37 ページ ２０１６年１２月１３日 火曜日 午前１１時１８分

Yamaha MT 10 Specifications

General

Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Displacement	998cc
Bore x Stroke	79.0 mm x 50.9 mm
Compression Ratio	12.0 : 1
Maximum Power	118.0 kW (160.4 PS) @ 11, 500 rpm
Fuel System	Fuel Injection
Ignition System	TCI
Transmission	Constant mesh, 6-speed
Final Drive	Chain
Front Suspension	Telescopic forks
Front Tyre	120/70 ZR17 M/C (58W)
Rear Tyre	190/55 ZR17 M/C (75W)
Overall Length	2, 095 mm
Overall Width	800 mm
Overall Height	1, 110 mm
Seat Height	825 mm
Wheelbase	1, 405 mm
Minimum Ground Clearance	135 mm
Wet Weight	210 kg
Fuel Tank Capacity	17 litres
Maximum Torque	111 Nm (11.3 kg-m) @ 9, 000 rpm
Rear Suspension	Swingarm
Front Brake	Dual hydraulic disc
Rear Brake	Hydraulic disc
Frame	Aluminum Deltabox
