Yamaha MT07A - Description; Left View

DESCRIPTION
2-1
2
EAU10411
Left view
5678910
1 2 3,4
1. Auxiliary DC connector (page 3-27)
2. Seat lock (page 3-19)
3. Storage compartment (page 3-22)
4. Owner’s tool kit (page 6-2)
5. Shift pedal (page 3-14)
6. Engine oil filler cap (page 6-9)
7. Engine oil drain bolt (page 6-9)
8. Engine oil level check window (page 6-9)
9. Engine oil filter cartridge (page 6-9)
10.Coolant reservoir (page 6-11)
