INSTRUMENT AND CONTROL FUNCTIONS
3-6
3
EAU59976
Multi-function meter unit
WARNING
EWA12423
Be sure to stop the vehicle before
making any setting changes to the
multi-function meter unit. Changing
settings while riding can distract the
operator and increase the risk of an
accident.
The multi-function meter unit is
equipped with the following:
 a speedometer
 a tachometer
 a clock
 a fuel meter
 an eco indicator
 a transmission gear display
 a multi-function display
TIP
 Except when switching to the
brightness control mode or to dis-
play the clock, turn the key to
“ON” before using the left and
right set buttons to adjust the
multi-function meter.
 For the UK only: To switch the
speedometer and multi-function
display between kilometers and
miles, set the multi-function dis-
play to the odometer mode or a
tripmeter mode, and then press
the left set button for at least three
seconds.
Speedometer
The speedometer shows the vehicle’s
traveling speed.
1. Left set button
2. Right set button
1 2
1. Fuel meter
2. Clock
3. Transmission gear display
4. Eco indicator “ECO”
5. Speedometer
6. Tachometer
7. Multi-function display
67
21 3 4 5
