Yamaha MT07A - Controls and Instruments

DESCRIPTION
2-3
2
EAU10431
Controls and instruments
1 2 3 4 5 6 7 8
1. Clutch lever (page 3-14)
2. Left handlebar switches (page 3-13)
3. Multi-function meter unit (page 3-6)
4. Main switch/steering lock (page 3-2)
5. Front brake fluid reservoir (page 6-21)
6. Right handlebar switches (page 3-13)
7. Throttle grip (page 6-15)
8. Brake lever (page 3-14)
U1WSE2E0.book Page 3 Tuesday, October 7, 2014 9:17 AM
