Yamaha MT07M - Description; Left View

Description
3-1
3
EAU10411
Left view
1
45678910
23
1. Seat lock (page 4-17)
2. Battery (page 7-30)
3. Fuses (page 7-32)
4. Rebound damping force adjuster (page 4-19)
5. Shift pedal (page 4-11)
6. Engine oil filler cap (page 7-11)
7. Engine oil level check window (page 7-11)
8. Engine oil drain bolt (page 7-11)
9. Engine oil filter cartridge (page 7-11)
10.Coolant reservoir (page 7-14)
