Yamaha MT07M - Controls and Instruments

Description
3-3
3
EAU10431
Controls and instruments
12 3 45678
1. Clutch lever (page 4-11)
2. Left handlebar switches (page 4-9)
3. Multi-function meter unit (page 4-4)
4. Main switch/steering lock (page 4-1)
5. Front brake fluid reservoir (page 7-22)
6. Right handlebar switches (page 4-9)
7. Throttle grip (page 7-17)
8. Brake lever (page 4-12)
UBAT10E0.book Page 3 Friday, November 6, 2020 6:08 PM
