Effect Parameter List
[3] TEMPO DELAY MONO
[4] TEMPO DELAY STEREO
[5] CONTROL DELAY
[6] DELAY L, R
[7] DELAY L, C, R
[8] DELAY L, R (STEREO)
Category — CHORUS
[1] G CHORUS
*2: Insertion Block only.
[2] 2 MODULATOR
*2: Insertion Block only.
No. Parameter Range Value Table No .
1 Delay Time 32nd/3 – 4thX6 (0 – 19) 12
2 Feedback Level -63 – +63 (1 – 127)
3 Feedback High Damp 0.1 – 1.0 (1 – 10)
4 L/R Diffusion -63ms – +63ms (1 – 127)
5 Lag -63ms – +63ms (1 – 127)
6—
7—
8—
9—
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 —
12 —
13 – 16: Same as the parameters shaded in gray in CROSS DELAY on page 33.
No. Parameter Range Value Table No .
1 Delay Time 32nd/3 – 4thX6 (0 – 19) 12
2 Feedback Level -63 – +63 (1 – 127)
3 Feedback High Damp 0.1 – 1.0 (1 – 10)
4 L/R Diffusion -63ms – +63ms (1 – 127)
5 Lag -63ms – +63ms (1 – 127)
6—
7—
8—
9—
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 —
12 —
13 – 16: Same as the parameters shaded in gray in CROSS DELAY on page 33.
No. Parameter Range Value Table No .
1 Delay Time 0.1ms – 1486.0 ms (1 – 14860)
2 Delay Transition Rate 1 – 48 (1 – 48)
3 Feedback Level -63 – +63 (1 – 127)
4 Feedback High Damp 0.1 – 1.0 (1 – 10)
6 – 9: Same as the parameters shaded in gray in CROSS DELAY on page 33.
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 Control Type Normal, Scratch (0 – 1)
12 —
13 —
14 —
15 —
16 —
No. Parameter Range Value Table No .
1 Delay Time L 0.1ms – 1638.3 ms (1 – 16383)
2 Delay Time R 0.1ms – 1638.3 ms (1 – 16383)
3 Feedback Time 1 0.1ms – 1638.3 ms (1 – 16383)
4 Feedback Time 2 0.1ms – 1638.3 ms (1 – 16383)
5 Feedback Level -63 – +63 (1 – 127)
6 Feedback High Damp 0.1 – 1.0 (1 – 10)
7—
8—
9—
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 —
12 —
13 – 16: Same as the parameters shaded in gray in CROSS DELAY on page 33.
No. Parameter Range Value Table No.
1 Delay Time L 0.1ms – 1638.3 ms (1 – 16383)
2 Delay Time R 0.1ms – 1638.3 ms (1 – 16383)
3 Delay Time C 0.1ms – 1638.3 ms (1 – 16383)
4 Feedback Time 0.1ms – 1638.3 ms (1 – 16383)
5 Feedback Level -63 – +63 (1 – 127)
6 Delay Level C 0 – 127 (0 – 127)
7 Feedback High Damp 0.1 – 1.0 (1 – 10)
8—
9—
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 —
12 —
13 – 16: Same as the parameters shaded in gray in CROSS DELAY on page 33.
No. Parameter Range Value Table No.
1 Delay Time L 0.1ms – 1638.3 ms (1 – 16383)
2 Delay Time R 0.1ms – 1638.3 ms (1 – 16383)
3 Feedback Time L 0.1ms – 1638.3 ms (1 – 16383)
4 Feedback Time R 0.1ms – 1638.3 ms (1 – 16383)
5 Feedback Level -63 – +63 (1 – 127)
6 Feedback High Damp 0.1 – 1.0 (1 – 10)
7—
8—
9—
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 —
12 —
13 – 16: Same as the parameters shaded in gray in CROSS DELAY on page 33.
No. Parameter Range Value Table No.
1 LFO Speed 0.0Hz – 39.70Hz (0 – 127) 1
2—
3 PM Depth 0 – 127 (0 – 127)
4 Feedback Level -63 – +63 (1 – 127)
5 Delay Offset 0.0ms – 50.0ms (0 – 127) 2
6 – 9: Same as the parameters shaded in gray in CROSS DELAY on page 33.
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 EQ Mid Frequency (*2) 100Hz – 10.0kHz (14 – 54) 3
12 EQ Mid Gain (*2) -12dB – +12dB (52 – 76)
13 EQ Mid Width (*2) 0.1 – 12.0 (1 – 120)
14 —
15 Input Mode Mono, Stereo (0 – 1)
16 —
No. Parameter Range Value Table No.
1 LFO Speed 0.0Hz – 39.70Hz (0 – 127) 1
2 AM Depth 0 – 127 (0 – 127)
3 PM Depth 0 – 127 (0 – 127)
4 Feedback Level -63 – +63 (1 – 127)
5 Delay Offset 0.0ms – 50.0ms (0 – 127) 2
6 – 9: Same as the parameters shaded in gray in CROSS DELAY on page 33.
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 EQ Mid Frequency (*2) 100Hz – 10.0kHz (14 – 54) 3
12 EQ Mid Gain (*2) -12dB – +12dB (52 – 76)
13 EQ Mid Width (*2) 0.1 – 12.0 (1 – 120)
14 —
15 Input Mode Mono, Stereo (0 – 1)
16 —
