MX49/MX61 Data List
36
Effect Parameter List
[3] TEMPO PHASER
Category — TREMOLO&ROTARY
[1] AUTO PAN
[2] TREMOLO
[3] ROTARY SPEAKER
Category — DISTORTION
[1] AMP SIMULATOR 1
[2] AMP SIMULATOR 2
[3] COMP DISTORTION
No. Parameter Range Value Table No .
1 LFO Speed 16th – 4thX16 (5 – 29) 12
2 LFO Depth 0 – 127 (0 – 127)
3 Phase Shift Offset 0 – 127 (0 – 127)
4 Feedback Level -63 – +63 (1 – 127)
5 LFO Phase Reset Off (free run), Key On Reset,
SEQ Start Reset
(0 – 2)
6 – 9: Same as the parameters shaded in gray in CROSS DELAY on page 33.
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 Stage 4 – 22
(Chorus Block: 4 – 12)
(4 – 22)
(4 – 12)
12 Diffusion Mono, Stereo (0 – 1)
13 —
14 —
15 —
16 —
No. Parameter Range Value Table No .
1 LFO Speed 0.0Hz – 39.70Hz (0 – 127) 1
2 L/R Depth 0 – 127 (0 – 127)
3 F/R Depth 0 – 127 (0 – 127)
4 Pan Direction L<>R, L>>R, L<<R, L Turn,
R Turn, L/R
(0 – 5)
5 LFO Wave 0 – 28 (0 – 28)
6 – 9: Same as the parameters shaded in gray in CROSS DELAY on page 33.
10 —
11 EQ Mid Frequency 100Hz – 10.0kHz (14 – 54) 3
12 EQ Mid Gain -12dB – +12dB (52 – 76)
13 EQ Mid Width 0.1 – 12.0 (1 – 120)
14 —
15 Input Mode Mono, Stereo (0 – 1)
16 —
No. Parameter Range Value Table No .
1 LFO Speed 0.0Hz – 39.70Hz (0 – 127) 1
2 AM Depth 0 – 127 (0 – 127)
3 PM Depth 0 – 127 (0 – 127)
4—
5—
6 – 9: Same as the parameters shaded in gray in CROSS DELAY on page 33.
10 —
11 EQ Mid Frequency 100Hz – 10.0kHz (14 – 54) 3
12 EQ Mid Gain -12dB – +12dB (52 – 76)
13 EQ Mid Width 0.1 – 12.0 (1 – 120)
14 LFO Phase Difference -180deg – +180deg (4 – 124)
15 Input Mode Mono, Stereo (0 – 1)
16 —
No. Parameter Range Value Table No .
1 Rotor Speed Slow 0.0Hz – 2.65Hz (0 – 63) 1
2 Horn Speed Slow 0.0Hz – 2.65Hz (0 – 63) 1
3 Rotor Speed Fast 2.69Hz – 39.70Hz (64 – 127) 1
4 Horn Speed Fast 2.69Hz – 39.70Hz (64 – 127) 1
5 Slow-Fast Time of Rotor 0 – 127 (0 – 127)
6 Slow-Fast Time of Horn 0 – 127 (0 – 127)
7 Drive Rotor 0 – 127 (0 – 127)
8 Drive Horn 0 – 127 (0 – 127)
9 Rotor/Horn Balance R63>H – R=H – R<H63 (1 – 127)
10 —
11 – 14: Same as the parameters shaded in gray in CROSS DELAY on page 33.
15 Mic L-R Angle 0deg – 180deg (0 – 60)
16 Speed Control Slow, Fast (0 – 1)
No. Parameter Range Value Table No.
1 Overdrive 0 – 100% (0 – 100)
2 Device Transistor, Vintage Tube,
Distortion 1, Distortion 2,
Fuzz
(0 – 4)
3 Speaker Type Flat, Stack, Combo, Twin,
Radio, Megaphone
(0 – 5)
4 Presence -10 – +10 (0 – 20)
5 Output Level 0 – 100% (0 – 100)
6—
7—
8—
9—
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 —
12 —
13 —
14 —
15 —
16 —
No. Parameter Range Value Table No.
1 Overdrive 0 – 127 (0 – 127)
2 AMP Type Off, Stack, Combo, Tube,
Crunch, Hi Gain, British
(0 – 6)
3 LPF Cutoff Frequency 1.0kHz – 20.0kHz (34 – 60) 3
4 Output Level 0 – 127 (0 – 127)
5—
6—
7—
8—
9—
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 —
12 —
13 —
14 —
15 —
16 —
No. Parameter Range Value Table No.
1 Overdrive 0 – 127 (0 – 127)
2 EQ Low Frequency 32Hz – 2.0kHz (4 – 40) 3
3 EQ Low Gain -12dB – +12dB (52 – 76)
4 LPF Cutoff Frequency 1.0kHz – 20.0kHz (34 – 60) 3
5 Output Level 0 – 127 (0 – 127)
6—
7 EQ Mid Frequency 100Hz – 10.0kHz (14 – 54) 3
8 EQ Mid Gain -12dB – +12dB (52 – 76)
9 EQ Mid Width 0.1 – 12.0 (1 – 120)
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 Edge 0 – 127 (0 – 127)
12 Attack 1ms – 40ms (0 – 19) 8
13 Release 10ms – 680ms (0 – 15) 9
14 Threshold -48dB – -6dB (79 – 121)
15 Ratio 1.0 – 20.0 (0 – 7) 10
16 —
