MX49/MX61 Data List
38
Effect Parameter List
[3] VCM PEDAL WAH
When the value of Bottom is greater than Top, the sound will not be modulated and only the Bottom
value is available.
Category — Lo-Fi
[1] NOISY
[2] DIGITAL TURNTABLE
Category — TEC
[1] RING MODULATOR
[2] AUTO SYNTH
[3] ISOLATOR
[4] TECH MODULATION
No. Parameter Range Value Table No .
1 Pedal Control 0 – 127 (0 – 127)
2 Bottom 0 – 127 (0 – 127)
3 Top 0 – 127 (0 – 127)
4 Resonance Offset -12.0 – +12.0 (40 – 88)
5 Direction Up, Down (0 – 1)
6 Type High, Mid, Low, Bass (0 – 3)
7 Overdrive 0.0dB – +40.0dB (0 – 80)
8 Output -20.0dB – +10.0dB (24 – 84)
9—
10 —
11 —
12 —
13 —
14 —
15 —
16 —
No. Parameter Range Value Table No .
1 Mod Depth 0 – 10 (0 – 10)
2 Mod Speed 0 – 127 (0 – 127)
3 Mod Feedback -63 – +63 (1 – 127)
4 Mod Mix Balance 1 – 127 (1 – 127)
5 Drive 0 – 127 (0 – 127)
6 AM Speed 0.00Hz – 39.7Hz (0 – 127) 1
7 AM Depth 0 – 127 (0 – 127)
8 LPF Cutoff Frequency 1.0kHz – 20.0kHz (34 – 60) 3
9 LPF Resonance 1.0 – 12.0 (10 – 120)
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 EQ Frequency 100Hz – 10.0kHz (14 – 54) 3
12 EQ Gain -12dB – +12dB (52 – 76)
13 EQ Width 1.0 – 12.0 (10 – 120)
14 —
15 —
16 —
No. Parameter Range Value Table No .
1 Click Density 0 – 5 (0 – 5)
2 Click Level 0 – 127 (0 – 127)
3 Noise Tone 0 – 6 (0 – 6)
4 Noise Mod Speed 0.00Hz – 39.7Hz (0 – 127) 1
5 Noise Mod Depth 0 – 127 (0 – 127)
6 Dry Send to Noise 0 – 127 (0 – 127)
7 Noise LPF Cutoff Frequency 1.0kHz – 20.0kHz (34 – 60) 3
8 Noise LPF Q 1.0 – 12.0 (10 – 120)
9 Noise Level 0 – 127 (0 – 127)
10 —
11 Dry Level 0 – 127 (0 – 127)
12 Dry LPF Cutoff Frequency 1.0kHz – 20.0kHz (34 – 60) 3
13 —
14 —
15 —
16 —
No. Parameter Range Value Table No.
1 OSC Frequency Coarse 0.5Hz – 5kHz (0 – 127) 14
2 OSC Frequency Fine 0 – 127 (0 – 127)
3 LFO Wave Triangle, Sine (0 – 1)
4 LFO Depth 0 – 127 (0 – 127)
5 LFO Speed 0.0Hz – 39.70Hz (0 – 127) 1
6 HPF Cutoff Frequency 20Hz – 8.0kHz (0 – 52) 3
7 LPF Cutoff Frequency 1.0kHz – 20.0kHz (34 – 60) 3
8—
9—
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 —
12 —
13 – 16: Same as the parameters shaded in gray in CROSS DELAY on page 33.
No. Parameter Range Value Table No.
1 Mod Speed 0 – 127 (0 – 127)
2 Mod Wave Type Type A, Type B, Type C,
Type D
(0 – 3)
3 Mod Depth 0 – 127 (0 – 127)
4 Mod Depth Ofst R -63 – +63 (1 – 127)
5 HPF Cutoff Frequency 20Hz – 8.0kHz (0 – 52) 3
6 LPF Cutoff Frequency 1.0kHz – 20.0kHz (34 – 60) 3
7 Delay Time 0.1ms – 370.0ms (1 – 3700)
8 Delay Time Ofst R 0 – 884 (0 – 884)
9 Delay Level 0 – 127 (0 – 127)
10 Dry Mix Level 0 – 127 (0 – 127)
11 Feedback Level -63 – +63 (1 – 127)
12 FB Level Ofst R -63 – +63 (1 – 127)
13 AM Speed 0.00Hz – 39.7Hz (0 – 127) 1
14 AM Wave Triangle, Sine, Saw Up, Saw
Down
(0 – 3)
15 AM Depth 0 – 127 (0 – 127)
16 AM Inverse R Normal, Inverse (0 – 1)
No. Parameter Range Value Table No.
1 On/off Switch On, Off (0 – 1)
2 Low Level -64 – +63 (0 – 127)
3 Mid Level -64 – +63 (0 – 127)
4 High Level -64 – +63 (0 – 127)
5 Low Mute Off, On (0 – 1)
6 Mid Mute Off, On (0 – 1)
7 High Mute Off, On (0 – 1)
8—
9—
10 —
11 —
12 —
13 —
14 —
15 —
16 —
No. Parameter Range Value Table No.
1 Mod Speed 0 – 127 (0 – 127)
2 Mod Depth 0 – 127 (0 – 127)
3 Mod Gain -12 – +12dB (52 – 76)
4 Mod Mix Balance D63>W – D=W – D<W63 (1 – 127)
5 Pre Mod HPF Cutoff
Frequency
20Hz – 8.0kHz (0 – 52) 3
6 Mod LPF Cutoff Frequency 1.0kHz – 20.0kHz (34 – 60) 3
7 Mod LPF Resonance 1.0 – 12.0 (10 – 120)
8 Delay Time 0.1 – 740.0ms (1 – 7400)
9 Delay Time Ofst R 0 – 884 (0 – 884)
10 Dry/Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 Feedback Level -63 – +63 (1 – 127)
12 FB Level Ofst R -63 – +63 (1 – 127)
13 Feedback High Damp 0.1 – 1.0 (1 – 10)
14 FB Hi Damp Ofst R -0.9 – +0.9 (1 – 19)
15 —
16 —
