MX49/MX61 Data List
61
MIDI Data Table
TOTAL SIZE = 62 3E (HEX)
pp = part number 00 – 0F
Address
Size
Data
Range
(HEX)
Parameter Name Description
Default
(HEX)
Notes
High Mid Low
37 pp 00 1 reserved
01 1 00 – 7F Bank Select MSB 0 – 127 3F
02 1 00 – 7F Bank Select LSB 0 – 127 00
03 1 00 – 7F Program Number 1 – 128 00
04 1 00 – 0F,
7F
Receive Channel 1..16, off (7F) Part
No.
05 1 00 – 01 Mono/Poly mono, poly 01
06 1 01 – 7F Velocity Limit Low 1 – 127 01
07 1 01 – 7F Velocity Limit High 1 – 127 7F
08 1 00 – 7F Note Limit Low C-2 – G8 00
09 1 00 – 7F Note Limit High C-2 – G8 7F
0A 1 10 – 4C Pitch Bend Range Upper -48 – +12 42
0B 1 10 – 4C Pitch Bend Range Lower -48 – +12 3E
0C 1 00 – 7F Velocity Sensitivity Depth 0 – 127 40
0D 1 00 – 7F Velocity Sensitivity Offset 0 – 127 40
0E 1 00 – 7F Volume 0 – 127 64
0F 1 01 – 7F Pan L63 – C – R63 40
10 2 00 – 0F
00 – 0F
Detune -12.8 – +12.7 [Hz]
1st bit 3-0 bit 7-4,
2nd bit 3-0 bit 3-0
08
00
(80)
12 1 00 – 7F Reverb Send 0 – 127 0C
13 1 00 – 7F Chorus Send 0 – 127 00
14 1 reserved
15 1 00 – 7F Dry Level 0 – 127 7F
16 1 28 – 58 Note Shift -24 – +24 [semitones] 40
17 1 reserved
18 1 00 – 01 Param. with Voice off, on 01
19 1 reserved
1A 1 00 – 01 Portamento Switch off, on 00
1B 1 00 – 7F Portamento Time 0 – 127 40
1C 1 00 – 01 Portamento Mode fingered, fulltime 01
1D 1 reserved
1E 1 reserved
37 pp 1F 1 18 – 7C Receive PB
Receive AT
Receive Program Change
Receive Bank Select
Receive Control Change
reserved
bit 6: off, on PB
bit 5: off, on AT
bit 4: off, on Program
Change
bit 3: off, on Bank Select
bit 2: off, on Control
Change
bit 1-0: reserved
7C
20 1 02 – 6F Receive FC2
Receive FC1
reserved
Receive MW
Receive Sustain/Sostenuto
Receive Pan
Receive Volume/Expression
bit 6: off, on FC2
bit 5: off, on FC1
bit 4: reserved
bit 3: off, on MW
bit 2: off, on Sustain/
Sostenuto
bit 1: off, on Pan
bit 0: off, on Volume/
Expression
6F
21 1 00 – 7F Receive Assignable Switch
2
Receive Assignable Switch
1
Receive Assignable Knob 2
Receive Assignable Knob 1
Receive RB
Receive BC
Receive FS
bit 6: off, on ASW2
bit 5: off, on ASW1
bit 4: off, on AKN2
bit 3: off, on AKN1
bit 2: off, on RB
bit 1: off, on BC
bit 0: off, on FS
7F
37 pp 22 1 00 – 01 Voice Element Pan off, on 01
23 1 00 – 7F AEG Attack Time -64 – +63 40
24 1 00 – 7F AEG Decay Time -64 – +63 40
25 1 00 – 7F AEG Sustain Level -64 – +63 40 Only for
Normal
Voice
26 1 00 – 7F AEG Release Time -64 – +63 40 Only for
Normal
Voice
27 1 00 – 7F FEG Attack Time -64 – +63 40 Only for
Normal
Voice
28 1 00 – 7F FEG Decay Time -64 – +63 40 Only for
Normal
Voice
29 1 00 – 7F FEG Sustain Level -64 – +63 40 Only for
Normal
Voice
2A 1 00 – 7F FEG Release Time -64 – +63 40 Only for
Normal
Voice
2B 1 00 – 7F FEG Depth -64 – +63 40 Only for
Normal
Voice
2C 1 reserved
2D 1 00 – 7F Filter Cutoff Frequency -64 – +63 40
2E 1 00 – 7F Filter Resonance -64 – +63 40
37 pp 2F 1 reserved
30 1 reserved
31 1 reserved
32 1 reserved
33 1 reserved
34 1 reserved
35 1 reserved
36 1 reserved
37 1 reserved
38 1 reserved
39 1 reserved
3A 1 reserved
3B 1 reserved
37 pp 3C 1 00 – 7F Assignable Knob 1 Value -64 – +63 40
3D 1 00 – 7F Assignable Knob 2 Value -64 – +63 40
Address
Size
Data
Range
(HEX)
Parameter Name Description
Default
(HEX)
Notes
High Mid Low
38 pp 00 1 00 – 01 ARP Switch off, on 00
01 1 00 – 01 ARP MIDI Out Switch off, on 00
02 1 00 – 0F ARP Transmit Channel 1..16 Part No.
03 1 00 – 01 ARP Play Only off, on 00 Determines
whether or not
the current Part
plays only the
note events of
the Arpeggio
playback
04 1 reserved
05 1 reserved
06 1 00 – 01 ARP Loop off, on 01
07 1 00 – 02 ARP Hold sync-off, off, on 01
08 1 00 – 06 ARP Unit Multiply 50%, 66%, 75%,
100%, 133%, 150%,
200%
03
09 1 00 – 7F ARP Note Limit Low C-2..G8 00
0A 1 00 – 7F ARP Note Limit High C-2..G8 7F
0B 1 01 – 7F ARP Velocity Limit Low 1 – 127 01
0C 1 01 – 7F ARP Velocity Limit High 1 – 127 7F
0D 1 00 – 04 ARP Key Mode sort, thru, direct,
sort+direct,
thru+direct
00
0E 1 00 – 01 ARP Velocity Mode original, thru 00
0F 1 00 – 01 ARP Change Timing realtime, measure 01
10 1 01 – 07 ARP Quantize Value 32th, 16th_Triplet,
16th, 8th_Triplet, 8th,
4th_Triplet, 4th
03
11 1 00 – 64 ARP Quantize Strength 0...100% 00
12 2 00 – 01
00 – 48
ARP Velocity Rate 0...200% 00 64
14 2 00 – 01
00 – 48
ARP Gate Time Rate 0...200% 00
64
16 1 reserved
17 1 reserved
18 1 reserved
19 1 reserved
1A 2 00 – 01
08 – 78
ARP Swing -120 … 0 … +120 01
00
1C 1 00 – 7F ARP Accent Velocity
Threshold
off, 1 … 127 40
1D 1 00 – 01 ARP Accent Start
Quantize
off, on 01
1E 1 3D – 43 ARP Octave Range -3 … 0 … +3 40
1F 1 36 – 4A ARP Output Octave Shift -10 … 0 … +10 40
20 1 00 – 01 ARP Trigger Mode gate, toggle 00
21 1 00 – 01 ARP Random SFX off, on 01
22 1 00 – 01 ARP Random SFX Key
On Control
off, on 01
23 1 00 – 7F ARP Random SFX
Velocity Offset
-64 … 0 … +63 40
24 2 00 – 01
1C – 64
ARP Assign Velocity
Rate Offset SF1
-100 … 0 … +100 01
00
26 2 00 – 01
1C – 64
ARP Assign Gate Time
Offset SF1
-100 … 0 … +100 01
00
28 2 00 – 01
1C – 64
ARP Assign Velocity
Rate Offset SF2
-100 … 0 … +100 01
00
2A 2 00 – 01
1C – 64
ARP Assign Gate Time
Offset SF2
-100 … 0 … +100 01
00
2C 2 00 – 01
1C – 64
ARP Assign Velocity
Rate Offset SF3
-100 … 0 … +100 01
00
2E 2 00 – 01
1C – 64
ARP Assign Gate Time
Offset SF3
-100 … 0 … +100 01
00
30 2 00 – 01
1C – 64
ARP Assign Velocity
Rate Offset SF4
-100 … 0 … +100 01
00
32 2 00 – 01
1C – 64
ARP Assign Gate Time
Offset SF4
-100 … 0 … +100 01
00
34 2 00 – 01
1C – 64
ARP Assign Velocity
Rate Offset SF5
-100 … 0 … +100 01
00
36 2 00 – 01
1C – 64
ARP Assign Gate Time
Offset SF5
-100 … 0 … +100 01
00
38 2 00 – 01
1C – 64
ARP Assign Velocity
Rate Offset SF6
-100 … 0 … +100 01
00
3A 2 00 – 01
1C – 64
ARP Assign Gate Time
Offset SF6
-100 … 0 … +100 01
00
Address
Size
Data
Range
(HEX)
Parameter Name Description
Default
(HEX)
Notes
High Mid Low
