Performance for customer Service Tip
Model : MX825V-EFI
7
• 2 inlet Valves.
• Adopt shim valve adjustment design.
Valve system
1) Multi valve (2 IN, 1 EX) , 2) Shim valve adjustment design.
• High performance
• Long maintenance interval
1) High performance, 2) Long maintenance interval.
• Valve clearance: IN 0.04～0.08mm
EX 0.08～0.12mm
• Periodical Check: 1,000 hr
• Shim increments: 0.05mm
2 Intake Valves
1 Exhaust Valve
Valve springs for intake are
different from that for exhaust
Shims for Valve clearance adjustment
(valve adjustment procedure outlined in the Service Tips section - Click
